Commercial
Non-Insulated
Terminals

Filter
10-220-11-05
10-220-11-05
10-220-11-05
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Electro Solder NO
10-873-3-04
10-873-3-04
10-873-3-04
0.285" 0.090 - Swage Mount 0.135" 3/32 0.094 Brass Electro-Tin YES
10-220-4-05
10-220-4-05
10-220-4-05
0.303" - - Swage Mount 0.147" 1/8 0.064 Brass Electro Solder NO
10-254-2A-05
10-254-2A-05
10-254-2A-05
0.254" - - Swage Mount 0.098" 1/16 0.063 Brass Electro Solder NO
10-871-2-088
10-871-2-088
10-871-2-088
0.428" 0.030 - Swage Mount 0.084" 1/16 0.067 Brass Bright Tin-Lead NO
10-510-2-05
10-510-2-05
10-510-2-05
0.472" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.116 Brass Electro Solder NO
10-405-4-05
10-405-4-05
10-405-4-05
0.489" - - Swage Mount 0.172" 1/8 0.116 Brass Electro Solder NO
09-8311-4-01
09-8311-4-01
09-8311-4-01
0.331" 0.040 - Swage Mount 0.145" 1/8 0.076 Brass Silver YES
10-502-2-01
10-502-2-01
10-502-2-01
0.350" - TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.076 Brass Silver YES
10-801-1-01
10-801-1-01
10-801-1-01
0.379" 0.040 TURRET/PIN Swage Mount 0.051" 1/32 0.076 Brass Silver YES
10-865-2-04
10-865-2-04
10-865-2-04
0.164" 0.030 - Swage Mount 0.084" 1/16 0.067 Brass Electro-Tin YES
10-520-4-035
10-520-4-035
10-520-4-035
1.102" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.266 Brass Gold YES
10-604-3-088
10-604-3-088
10-604-3-088
0.828" - - Swage Mount 0.141" 3/32 0.266 Brass Bright Tin-Lead NO
10-519-8-01
10-519-8-01
10-519-8-01
1.217" - Double Turret/Double Turret Swage Mount 0.281" 1/4 0.266 Brass Silver YES
09-7107-1A-044
09-7107-1A-044
09-7107-1A-044
0.230" 0.025 - RIVET MOUNT 0.035" 1/100 0.033 Brass Bright Tin YES
09-7170-2B-05
09-7170-2B-05
09-7170-2B-05
0.194" - - RIVET MOUNT 0.095" 19/256 0.035 Brass Electro Solder NO
10-431-1-05
10-431-1-05
10-431-1-05
0.125" - - Swage Mount 0.045" 1/32 0.036 Brass Electro Solder NO
10-902-2-044
10-902-2-044
10-902-2-044
0.282" 0.060 - Swage Mount 0.094" 1/16 0.064 Brass Bright Tin YES
10-938-1-035
10-938-1-035
10-938-1-035
0.385" 0.038 - Swage Mount 0.060" 1/32 0.042 Brass Gold YES
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
