Commercial
Non-Insulated
Terminals

Filter
09-7013-3-05
09-7013-3-05
09-7013-3-05
0.285" - - Swage Mount 0.125" 3/32 0.067 LEADED Red Brass Electro Solder NO
09-7013-3-01
09-7013-3-01
09-7013-3-01
0.285" - - Swage Mount 0.125" 3/32 0.067 LEADED Red Brass Silver YES
09-7012-2-044
09-7012-2-044
09-7012-2-044
0.255" - - Swage Mount 0.095" 1/16 0.067 Brass Bright Tin YES
09-7012-3-088
09-7012-3-088
09-7012-3-088
0.285" - - Swage Mount 0.125" 3/32 0.067 Brass Bright Tin-Lead NO
09-7012-3-044
09-7012-3-044
09-7012-3-044
0.285" - - Swage Mount 0.125" 3/32 0.067 Brass Bright Tin YES
09-7012-1-044
09-7012-1-044
09-7012-1-044
0.222" - - Swage Mount 0.062" 1/32 0.067 Brass Bright Tin YES
09-6007-1-044
09-6007-1-044
09-6007-1-044
0.555" 0.025 SQ. - Press Fit/Solder 0.080" 1/16 0.055 Brass Bright Tin YES
09-0375-2-044
09-0375-2-044
09-0375-2-044
0.242" 0.062 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Bright Tin YES
09-0365-2-03
09-0365-2-03
09-0365-2-03
0.285" - - 2-56 - - 2-56 THREAD Brass Gold YES
09-0363-1-044
09-0363-1-044
09-0363-1-044
0.315" 0.025 - Press Fit/Solder 0.128" 1/16 TO 3/32 0.055 Brass Bright Tin YES
09-0361-1-01
09-0361-1-01
09-0361-1-01
0.315" - - Press Fit/Solder 0.138" 3/32 0.052 Brass Silver YES
09-0361-1-03
09-0361-1-03
09-0361-1-03
0.315" - - Press Fit/Solder 0.138" 3/32 0.052 Brass Gold YES
09-0361-1-04
09-0361-1-04
09-0361-1-04
0.315" - - Press Fit/Solder 0.138" 3/32 0.052 Brass Electro-Tin YES
09-0361-1-044
09-0361-1-044
09-0361-1-044
0.315" - - Press Fit/Solder 0.138" 3/32 0.052 Brass Bright Tin YES
09-0360-1-035
09-0360-1-035
09-0360-1-035
0.276" - - Press Fit/Solder 0.138" 3/32 0.052 Brass Gold YES
09-0356-1-035
09-0356-1-035
09-0356-1-035
0.108" 0.029 (+0.003/-0.001) - - 0.093" - - Brass Gold YES
09-0356-1-05
09-0356-1-05
09-0356-1-05
0.108" 0.029 (+0.003/-0.001) - - 0.093" - - Brass Electro Solder NO
09-0353-3-03
09-0353-3-03
09-0353-3-03
0.405" - - Swage Mount 0.115" 3/32 0.067 Brass Gold YES
09-0353-4-035
09-0353-4-035
09-0353-4-035
0.438" - - Swage Mount 0.148" 1/8 0.067 Brass Gold YES
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
