Commercial
Non-Insulated
Terminals

Filter
09-0271-1-03
09-0271-1-03
09-0271-1-03
0.130" 0.029 (+0.003/-0.001) - - 0.115" - - Brass Gold YES
09-0270-2-088
09-0270-2-088
09-0270-2-088
0.325" 0.052 - - - - - Brass Bright Tin-Lead NO
09-0270-2-01
09-0270-2-01
09-0270-2-01
0.325" 0.052 - - - - - Brass Silver YES
09-0268-1-05
09-0268-1-05
09-0268-1-05
0.368" - - Swage Mount 0.078" 1/32 0.094 Brass Electro Solder NO
09-0268-1-04
09-0268-1-04
09-0268-1-04
0.368" - - Swage Mount 0.078" 1/32 0.094 Brass Electro-Tin YES
09-0263-1-05
09-0263-1-05
09-0263-1-05
0.140" - - Swage Mount 0.125" 3/32 0.043 Brass Electro Solder NO
09-0260-1-044
09-0260-1-044
09-0260-1-044
0.376" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Bright Tin YES
09-0260-1-05
09-0260-1-05
09-0260-1-05
0.376" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Electro Solder NO
09-0260-1-04
09-0260-1-04
09-0260-1-04
0.376" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Electro-Tin YES
09-0258-1-095
09-0258-1-095
09-0258-1-095
0.346" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Hot Solder Dip NO
09-0258-1-04
09-0258-1-04
09-0258-1-04
0.346" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Electro-Tin YES
09-0258-1-05
09-0258-1-05
09-0258-1-05
0.346" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Electro Solder NO
09-0258-1-044
09-0258-1-044
09-0258-1-044
0.346" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Bright Tin YES
09-0253-2-01
09-0253-2-01
09-0253-2-01
0.268" - - Swage Mount 0.082" 1/16 0.081 Brass Silver YES
09-0249-2-01
09-0249-2-01
09-0249-2-01
0.175" - - Swage Mount 0.082" 1/16 0.070 Brass Silver YES
09-0245-3-05
09-0245-3-05
09-0245-3-05
0.336" 0.040 - Solder 0.113" 1/64 TO 3/32 0.043 Brass Electro Solder NO
09-0245-3-035
09-0245-3-035
09-0245-3-035
0.336" 0.040 - Solder 0.113" 1/64 TO 3/32 0.043 Brass Gold YES
09-0245-3-03
09-0245-3-03
09-0245-3-03
0.336" 0.040 - Solder 0.113" 1/64 TO 3/32 0.043 Brass Gold YES
09-0244-1-03
09-0244-1-03
09-0244-1-03
0.810" - - 8-32 - - 8-32 THREAD Brass Gold YES
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
