Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
09-0244-1-01	0.810"	-	-	8-32	-	-	8-32 THREAD	Brass	Silver	YES
09-0244-1-044	0.810"	-	-	8-32	-	-	8-32 THREAD	Brass	Bright Tin	YES
09-0243-1-04	0.550"	-	-	-	-	-	-	Beryllium Copper	Electro-Tin	YES
09-0243-1-01	0.550"	-	-	-	-	-	-	Beryllium Copper	Silver	YES
09-0243-1-044	0.550"	-	-	-	-	-	-	Beryllium Copper	Bright Tin	YES
09-0241-2-044	0.355"	-	-	2-56	-	-	2-56 THREAD	Brass	Bright Tin	YES
09-0241-1-03	0.293"	-	-	2-56	-	-	2-56 THREAD	Brass	Gold	YES
09-0241-2-088	0.355"	-	-	2-56	-	-	2-56 THREAD	Brass	Bright Tin-Lead	NO
09-0241-1-05	0.293"	-	-	2-56	-	-	2-56 THREAD	Brass	Electro Solder	NO
09-0239-3-088	0.306"	-	-	Swage Mount	0.115"	3/32	0.076	Brass	Bright Tin-Lead	NO
09-0239-3-095	0.306"	-	-	Swage Mount	0.115"	3/32	0.076	Brass	Hot Solder Dip	NO
09-0234-4-035	0.490"	-	-	Swage Mount	0.180"	5/32	0.067	Brass	Gold	YES
09-0226-2-01	0.325"	-	-	Swage Mount	0.115"	3/32	0.067	Brass	Silver	YES
09-0226-2-03	0.325"	-	-	Swage Mount	0.115"	3/32	0.067	Brass	Gold	YES
09-0222-1-01	0.693"	-	-	Solder	0.100"	1/16	0.096	Brass	Silver	YES
09-0222-1-044	0.693"	-	-	Solder	0.100"	1/16	0.096	Brass	Bright Tin	YES
09-0222-1-035	0.693"	-	-	Solder	0.100"	1/16	0.096	Brass	Gold	YES
09-0222-1-03	0.693"	-	-	Solder	0.100"	1/16	0.096	Brass	Gold	YES
09-0222-1-04	0.693"	-	-	Solder	0.100"	1/16	0.096	Brass	Electro-Tin	YES
10-823-2-05	0.564"	0.037 (TAPER)	DOUBLE TURRET/TAPER PIN	Swage Mount	0.087"	1/16	0.120	Brass	Electro Solder	NO
