Commercial
Non-Insulated
Terminals

Filter
10-133-11-088
10-133-11-088
10-133-11-088
0.077" - - Swage Mount 0.037" 1/64 0.033 Brass Bright Tin-Lead NO
10-459-2-095
10-459-2-095
10-459-2-095
0.240" - - Swage Mount 0.084" 1/16 0.064 Brass Hot Solder Dip NO
10-477-2-01
10-477-2-01
10-477-2-01
0.240" - - Swage Mount 0.084" 1/16 0.063 Brass Silver YES
09-8151-2-044
09-8151-2-044
09-8151-2-044
0.344" 0.038 - Swage Mount 0.094" 1/16 0.0635 Brass Bright Tin YES
10-447-4-035
10-447-4-035
10-447-4-035
0.428" - - Swage Mount 0.147" 1/8 0.063 Brass Gold YES
10-430-3-01
10-430-3-01
10-430-3-01
0.271" - - Swage Mount 0.115" 3/32 0.064 Brass Silver YES
10-454-4-088
10-454-4-088
10-454-4-088
0.406" - - Swage Mount 0.156" 1/8 0.067 Brass Bright Tin-Lead NO
10-401-4-044
10-401-4-044
10-401-4-044
0.312" - - Swage Mount 0.156" 1/8 0.067 Brass Bright Tin YES
10-522-2-04
10-522-2-04
10-522-2-04
0.574" - Turret/Turret Swage Mount 0.105" 1/16 0.206 Brass Electro-Tin YES
09-0026-2-035
09-0026-2-035
09-0026-2-035
0.281" - - Swage Mount 0.094" 1/16 0.076 Brass Gold YES
10-914-1-095
10-914-1-095
10-914-1-095
0.250" - - Swage Mount 0.062" 1/32 0.0635 Brass Hot Solder Dip NO
10-240-1-095
10-240-1-095
10-240-1-095
0.439" - - Swage Mount 0.075" 1/32 0.116 Brass Hot Solder Dip NO
10-512-8-095
10-512-8-095
10-512-8-095
0.661" - Double Turret/Double Turret Swage Mount 0.290" 1/4 0.129 Brass Hot Solder Dip NO
10-417-2-095
10-417-2-095
10-417-2-095
0.500" - - Swage Mount 0.109" 1/16 0.116 Brass Hot Solder Dip NO
09-0264-2-095
09-0264-2-095
09-0264-2-095
0.350" 0.040 DOUBLE TURRET/PIN Swage Mount 0.084" 1/16 0.076 Brass Hot Solder Dip NO
09-0210-5-095
09-0210-5-095
09-0210-5-095
0.330" - - 2-56 - - 2-56 THREAD Brass Hot Solder Dip NO
10-832-4-088
10-832-4-088
10-832-4-088
0.406" 0.050 - Swage Mount 0.156" 1/8 0.064 Brass Bright Tin-Lead NO
09-9501-1-088
09-9501-1-088
09-9501-1-088
0.344" 0.040 - 0-80 Screw - 1/16 CLEARANCE FOR #0 Screw Brass Bright Tin-Lead NO
10-401-4-035
10-401-4-035
10-401-4-035
0.312" - - Swage Mount 0.156" 1/8 0.067 Brass Gold YES
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO
