Commercial
Non-Insulated
Terminals

Filter
09-0339-4-088
09-0339-4-088
09-0339-4-088
0.597" - - Swage Mount 0.147" 1/8 0.063 Brass Bright Tin-Lead NO
09-0151-2-088
09-0151-2-088
09-0151-2-088
0.501" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Bright Tin-Lead NO
10-8012-1-088
10-8012-1-088
10-8012-1-088
0.306" 0.040 (+0.000/-0.003) - Solder - - 0.044 Brass Bright Tin-Lead NO
09-8791-1-088
09-8791-1-088
09-8791-1-088
0.200" 0.045 - - - - - Brass Bright Tin-Lead NO
10-917-2-088
10-917-2-088
10-917-2-088
0.252" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Bright Tin-Lead NO
10-329-4-088
10-329-4-088
10-329-4-088
0.500" - - Swage Mount 0.172" 1/8 0.125 Brass Bright Tin-Lead NO
09-8598-2-088
09-8598-2-088
09-8598-2-088
0.144" - - Swage Mount 0.084" 1/16 0.035 Brass Bright Tin-Lead NO
10-438-4-088
10-438-4-088
10-438-4-088
0.484" - - Swage Mount 0.172" 1/8 0.116 Brass Bright Tin-Lead NO
10-218-2-088
10-218-2-088
10-218-2-088
0.342" - - Swage Mount 0.105" 1/16 0.094 Brass Bright Tin-Lead NO
10-807-2-088
10-807-2-088
10-807-2-088
0.452" - - Swage Mount 0.109" 1/16 0.094 Brass Bright Tin-Lead NO
09-0320-1-088
09-0320-1-088
09-0320-1-088
0.281" - - Press Fit/Solder 0.195" 3/16 TO 7/32 0.055 Brass Bright Tin-Lead NO
10-519-4-088
10-519-4-088
10-519-4-088
1.092" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.266 Brass Bright Tin-Lead NO
10-812-3-088
10-812-3-088
10-812-3-088
0.625" - Turret/Turret Swage Mount 0.125" 3/32 0.147 Brass Bright Tin-Lead NO
10-349-2-088
10-349-2-088
10-349-2-088
0.437" - - Swage Mount 0.109" 1/16 0.116 Brass Bright Tin-Lead NO
09-0284-9-088
09-0284-9-088
09-0284-9-088
0.462" - - 2-56 - - 2-56 THREAD Brass Bright Tin-Lead NO
10-812-6-088
10-812-6-088
10-812-6-088
0.719" - Turret/Turret Swage Mount 0.219" 3/16 0.147 Brass Bright Tin-Lead NO
10-106-4-088
10-106-4-088
10-106-4-088
0.346" - - Swage Mount 0.165" 1/8 0.094 Brass Bright Tin-Lead NO
10-807-6-088
10-807-6-088
10-807-6-088
0.577" - - Swage Mount 0.234" 3/16 0.094 Brass Bright Tin-Lead NO
10-807-4-088
10-807-4-088
10-807-4-088
0.515" - - Swage Mount 0.172" 1/8 0.094 Brass Bright Tin-Lead NO
09-0164-3-088
09-0164-3-088
09-0164-3-088
0.371" - - Swage Mount 0.121" 3/32 0.125 Brass Bright Tin-Lead NO
