Commercial
Non-Insulated
Terminals

Filter
10-136-1-095
10-136-1-095
10-136-1-095
0.149" - - Swage Mount 0.055" 1/32 0.041 Brass Hot Solder Dip NO
10-520-4-095
10-520-4-095
10-520-4-095
1.102" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.266 Brass Hot Solder Dip NO
10-101-3-095
10-101-3-095
10-101-3-095
0.217" - - Swage Mount 0.113" 3/32 0.076 Brass Hot Solder Dip NO
09-0260-1-095
09-0260-1-095
09-0260-1-095
0.376" (0.040 (+0.000/-0.003))/(0.040) Pin/Pin Solder 0.064" 1/32 0.070 Brass Hot Solder Dip NO
09-0292-4-044
09-0292-4-044
09-0292-4-044
0.482" 0.065 - 4-40 - - 4-40 THREAD Brass Bright Tin YES
10-810-6-044
10-810-6-044
10-810-6-044
0.546" - - Swage Mount 0.234" 3/16 0.1495 Brass Bright Tin YES
10-238-1-044
10-238-1-044
10-238-1-044
0.499" - - Swage Mount 0.078" 1/32 0.116 Brass Bright Tin YES
10-238-3-044
10-238-3-044
10-238-3-044
0.562" - - Swage Mount 0.141" 3/32 0.116 Brass Bright Tin YES
10-405-8-044
10-405-8-044
10-405-8-044
0.614" - - Swage Mount 0.297" 1/4 0.116 Brass Bright Tin YES
10-332-4A-044
10-332-4A-044
10-332-4A-044
0.781" - - Swage Mount 0.156" 1/8 0.125 Brass Bright Tin YES
09-0252-2-044
09-0252-2-044
09-0252-2-044
0.186" - - Swage Mount 0.082" 1/16 0.081 Brass Bright Tin YES
10-886-3-044
10-886-3-044
10-886-3-044
0.395" 0.030 - Swage Mount 0.125" 3/32 0.0635 Brass Bright Tin YES
10-961-3-044
10-961-3-044
10-961-3-044
0.229" - - Swage Mount 0.125" 3/32 0.0635 Brass Bright Tin YES
10-921-4-044
10-921-4-044
10-921-4-044
0.364" 0.045 - Swage Mount 0.156" 1/8 0.064 Brass Bright Tin YES
09-0339-4-044
09-0339-4-044
09-0339-4-044
0.597" - - Swage Mount 0.147" 1/8 0.063 Brass Bright Tin YES
10-964-2-044
10-964-2-044
10-964-2-044
0.174" 0.025 - Swage Mount 0.082" 1/16 0.035 Brass Bright Tin YES
10-101-1-04
10-101-1-04
10-101-1-04
0.155" - - Swage Mount 0.051" 1/32 0.076 Brass Electro-Tin YES
09-6011-2-05
09-6011-2-05
09-6011-2-05
0.672" 0.025 SQ. - Press Fit/Solder 0.132" 1/16 TO 3/32 0.059 Brass Electro Solder NO
09-0020-4-035
09-0020-4-035
09-0020-4-035
0.585" 0.094 - Swage Mount 0.165" 1/8 0.116 Brass Gold YES
10-434-4-03
10-434-4-03
10-434-4-03
0.433" - - Swage Mount 0.165" 1/8 0.189 Brass Gold YES
