Commercial
Non-Insulated
Terminals

Filter
10-971-2-01
10-971-2-01
10-971-2-01
0.602" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
09-8161-2-01
09-8161-2-01
09-8161-2-01
1.084" 0.0405 - Swage Mount 0.084" 1/16 0.043 Brass Silver YES
10-893-2-01
10-893-2-01
10-893-2-01
0.982" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
10-917-2-035
10-917-2-035
10-917-2-035
0.252" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
10-519-4-01
10-519-4-01
10-519-4-01
1.092" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.266 Brass Silver YES
10-975-2-01
10-975-2-01
10-975-2-01
1.102" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
09-8090-2-01
09-8090-2-01
09-8090-2-01
0.370" 0.020 - Solder 0.100" 1/16 0.024 Brass Silver YES
10-974-3-04
10-974-3-04
10-974-3-04
1.133" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Electro-Tin YES
09-8162-2-01
09-8162-2-01
09-8162-2-01
1.172" 0.0405 - Swage Mount 0.084" 1/16 0.043 Brass Silver YES
09-8059-2-03
09-8059-2-03
09-8059-2-03
0.582" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
09-8115-2-035
09-8115-2-035
09-8115-2-035
0.240" 0.040 - Swage Mount 0.090" 1/16 0.043 Brass Gold YES
10-8021-3-01
10-8021-3-01
10-8021-3-01
0.433" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Silver YES
09-8044-1-03
09-8044-1-03
09-8044-1-03
0.371" 0.031 - Swage Mount 0.051" 1/32 0.043 Brass Gold YES
09-8045-1-05
09-8045-1-05
09-8045-1-05
0.221" 0.031 - Swage Mount 0.051" 1/32 0.043 Brass Electro Solder NO
09-8174-11-04
09-8174-11-04
09-8174-11-04
0.935" 0.025 (+0.000/-0.005) - Swage Mount 0.035" 1/64 0.043 Brass Electro-Tin YES
09-7154-2-03
09-7154-2-03
09-7154-2-03
0.155" 0.023 - RIVET MOUNT 0.036" 1/100 0.035 Brass Gold YES
10-227-3-035
10-227-3-035
10-227-3-035
0.271" - - Swage Mount 0.115" 3/32 0.043 Brass Gold YES
10-216-6-01
10-216-6-01
10-216-6-01
0.467" - - Swage Mount 0.230" 3/16 0.094 Brass Silver YES
19-246-6-05
19-246-6-05
19-246-6-05
0.593" - - Swage Mount 0.234" 3/16 0.116 LEADED Red Brass Electro Solder NO
10-8011-6-01
10-8011-6-01
10-8011-6-01
0.484" - - Swage Mount 0.234" 3/16 0.116 Brass Silver YES
