Commercial
Non-Insulated
Terminals

Filter
10-878-1-05
10-878-1-05
10-878-1-05
0.384" 0.040 Pin/Pin Swage Mount 0.051" 1/32 0.076 Brass Electro Solder NO
10-878-2-044
10-878-2-044
10-878-2-044
0.415" 0.040 Pin/Pin Swage Mount 0.082" 1/16 0.076 Brass Bright Tin YES
09-7153-2-01
09-7153-2-01
09-7153-2-01
0.271" 0.040 - RIVET MOUNT 0.103" 1/16 0.076 Brass Silver YES
09-8311-4-088
09-8311-4-088
09-8311-4-088
0.331" 0.040 - Swage Mount 0.145" 1/8 0.076 Brass Bright Tin-Lead NO
09-8311-1-044
09-8311-1-044
09-8311-1-044
0.237" 0.040 - Swage Mount 0.051" 1/32 0.076 Brass Bright Tin YES
09-8298-1-05
09-8298-1-05
09-8298-1-05
0.248" 0.040 - Swage Mount 0.075" 1/32 0.076 Brass Electro Solder NO
09-7153-2-03
09-7153-2-03
09-7153-2-03
0.271" 0.040 - RIVET MOUNT 0.103" 1/16 0.076 Brass Gold YES
09-8298-1-03
09-8298-1-03
09-8298-1-03
0.248" 0.040 - Swage Mount 0.075" 1/32 0.076 Brass Gold YES
09-8311-2-04
09-8311-2-04
09-8311-2-04
0.268" 0.040 - Swage Mount 0.082" 1/16 0.076 Brass Electro-Tin YES
09-7173-2-01
09-7173-2-01
09-7173-2-01
0.315" - - RIVET MOUNT 0.082" 1/16 0.035 Brass Silver YES
09-7151-2-01
09-7151-2-01
09-7151-2-01
0.422" 0.050 - RIVET MOUNT 0.104" 1/16 0.048 Brass Silver YES
09-7150-2-04
09-7150-2-04
09-7150-2-04
0.359" 0.050 - RIVET MOUNT 0.104" 1/16 0.048 Brass Electro-Tin YES
09-7150-2-05
09-7150-2-05
09-7150-2-05
0.359" 0.050 - RIVET MOUNT 0.104" 1/16 0.048 Brass Electro Solder NO
09-7149-2-035
09-7149-2-035
09-7149-2-035
0.328" 0.045 - RIVET MOUNT 0.104" 1/16 0.048 Brass Gold YES
09-8041-3-035
09-8041-3-035
09-8041-3-035
0.283" 0.032 TURRET/PC PIN Swage Mount 0.115" 3/32 0.067 Brass Gold YES
10-710-8-01
10-710-8-01
10-710-8-01
0.722" - DOUBLE TURRET/THREAD Swage Mount 0.285" 1/4 0.144 Brass Silver YES
10-802-1-01
10-802-1-01
10-802-1-01
0.272" 0.032 TURRET/PIN Swage Mount 0.054" 1/32 0.067 Brass Silver YES
10-501-11-01
10-501-11-01
10-501-11-01
0.223" - Turret/Turret Swage Mount 0.037" 1/64 0.076 Brass Silver YES
10-802-1-035
10-802-1-035
10-802-1-035
0.272" 0.032 TURRET/PIN Swage Mount 0.054" 1/32 0.067 Brass Gold YES
10-802-3-03
10-802-3-03
10-802-3-03
0.333" 0.032 TURRET/PIN Swage Mount 0.115" 3/32 0.067 Brass Gold YES
