Commercial
Non-Insulated
Terminals

Filter
10-806-4-035
10-806-4-035
10-806-4-035
0.599" - - Swage Mount 0.172" 1/8 0.094 Brass Gold YES
10-482-4-035
10-482-4-035
10-482-4-035
0.500" - - Swage Mount 0.172" 1/8 0.116 Brass Gold YES
10-372-4-035
10-372-4-035
10-372-4-035
0.303" - - Swage Mount 0.147" 1/8 0.064 Brass Gold YES
10-214-2A-035
10-214-2A-035
10-214-2A-035
0.250" - - Swage Mount 0.096" 1/16 0.067 Brass Gold YES
10-863-3-035
10-863-3-035
10-863-3-035
0.438" 0.040 - Swage Mount 0.125" 3/32 0.094 Brass Gold YES
10-103-2-035
10-103-2-035
10-103-2-035
0.343" - - Swage Mount 0.109" 1/16 0.116 Brass Gold YES
10-834-8-035
10-834-8-035
10-834-8-035
0.656" 0.050 - Swage Mount 0.281" 1/4 0.064 Brass Gold YES
09-8737-3-035
09-8737-3-035
09-8737-3-035
0.250" 0.060 - Swage Mount 0.100" 1/16 0.043 Brass Gold YES
09-0188-2-035
09-0188-2-035
09-0188-2-035
0.342" - - Swage Mount 0.105" 1/16 0.098 Brass Gold YES
10-468-2-03
10-468-2-03
10-468-2-03
0.344" - - Swage Mount 0.105" 1/16 0.094 Brass Gold YES
09-0151-2-03
09-0151-2-03
09-0151-2-03
0.501" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Gold YES
10-216-4-03
10-216-4-03
10-216-4-03
0.402" - - Swage Mount 0.165" 1/8 0.094 Brass Gold YES
10-8008-4-03
10-8008-4-03
10-8008-4-03
0.556" 0.080 - Swage Mount 0.156" 1/8 0.094 Brass Gold YES
10-459-4-03
10-459-4-03
10-459-4-03
0.303" - - Swage Mount 0.147" 1/8 0.064 Brass Gold YES
10-302-4-03
10-302-4-03
10-302-4-03
0.303" - - Swage Mount 0.147" 1/8 0.067 Brass Gold YES
09-0101-4-03
09-0101-4-03
09-0101-4-03
0.289" - - Swage Mount 0.130" 3/32 0.067 Brass Gold YES
10-543-2-03
10-543-2-03
10-543-2-03
0.539" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Gold YES
09-7020-2A-03
09-7020-2A-03
09-7020-2A-03
0.233" - - Swage Mount 0.093" 1/16 0.059 Brass Gold YES
09-0272-1-03
09-0272-1-03
09-0272-1-03
0.243" - - Swage Mount 0.055" 1/32 0.067 Brass Gold YES
10-907-1-03
10-907-1-03
10-907-1-03
0.453" 0.045 SLOTTED/PIN Press Fit/Solder 0.297" 1/16 0.047 Brass Gold YES
