Commercial
Non-Insulated
Terminals

Filter
09-8187-2-01
09-8187-2-01
09-8187-2-01
0.645" 0.020 - Solder 0.100" 1/64 TO 1/16 0.024 Brass Silver YES
09-8370-1-01
09-8370-1-01
09-8370-1-01
0.280" 0.0405 - Solder 0.030" 1/64 0.043 Brass Silver YES
10-522-5-044
10-522-5-044
10-522-5-044
0.664" - Turret/Turret Swage Mount 0.195" 5/32 0.206 Brass Bright Tin YES
10-465-4-04
10-465-4-04
10-465-4-04
0.547" - - Swage Mount 0.172" 1/8 0.1405 Brass Electro-Tin YES
10-815-4-04
10-815-4-04
10-815-4-04
0.365" - - Swage Mount 0.165" 1/8 0.1495 Brass Electro-Tin YES
10-918-2-04
10-918-2-04
10-918-2-04
0.402" 0.040 - Swage Mount 0.082" 1/16 0.043 Brass Electro-Tin YES
10-501-1A-044
10-501-1A-044
10-501-1A-044
0.254" - Turret/Turret Swage Mount 0.068" 1/32 0.076 Brass Bright Tin YES
10-101-8-044
10-101-8-044
10-101-8-044
0.374" - - Swage Mount 0.270" 1/4 0.076 Brass Bright Tin YES
10-808-6-04
10-808-6-04
10-808-6-04
0.705" - - Swage Mount 0.234" 3/16 0.094 Brass Electro-Tin YES
10-513-2-044
10-513-2-044
10-513-2-044
0.424" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.129 Brass Bright Tin YES
10-107-4-04
10-107-4-04
10-107-4-04
0.249" - - Swage Mount 0.156" 1/8 0.067 Brass Electro-Tin YES
09-0254-2-044
09-0254-2-044
09-0254-2-044
0.350" - TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.081 Brass Bright Tin YES
10-506-1-044
10-506-1-044
10-506-1-044
0.343" - Turret/Turret Swage Mount 0.062" 1/32 0.120 Brass Bright Tin YES
09-0040-1-044
09-0040-1-044
09-0040-1-044
1.1875" 0.055 - - - - - Brass Bright Tin YES
10-512-1-044
10-512-1-044
10-512-1-044
0.446" - Double Turret/Double Turret Swage Mount 0.075" 1/32 0.129 Brass Bright Tin YES
10-519-4-044
10-519-4-044
10-519-4-044
1.092" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.266 Brass Bright Tin YES
10-8013-1-044
10-8013-1-044
10-8013-1-044
0.297" 0.040 - - - - - Brass Bright Tin YES
10-490-6-05
10-490-6-05
10-490-6-05
0.634" - TURRET/SLOTTED Swage Mount 0.228" 3/16 0.120 Brass Electro Solder NO
10-465-3-05
10-465-3-05
10-465-3-05
0.516" - - Swage Mount 0.141" 3/32 0.1405 Brass Electro Solder NO
10-137-1-01
10-137-1-01
10-137-1-01
0.237" - - Swage Mount 0.078" 1/32 0.094 Brass Silver YES
