Commercial
Non-Insulated
Terminals

Filter
09-8349-2-01
09-8349-2-01
09-8349-2-01
0.270" 0.018 - Solder 0.100" 1/64 TO 1/16 0.020 Brass Silver YES
10-464-2-03
10-464-2-03
10-464-2-03
0.154" - - Swage Mount 0.084" 1/16 0.035 Brass Gold YES
10-424-4-088
10-424-4-088
10-424-4-088
0.602" - - Swage Mount 0.165" 1/8 0.141 Brass Bright Tin-Lead NO
09-8687-2-05
09-8687-2-05
09-8687-2-05
0.590" 0.040 Pin/Pin Swage Mount 0.090" 1/16 0.140 Brass Electro Solder NO
09-8251-2A-088
09-8251-2A-088
09-8251-2A-088
0.197" - - Swage Mount 0.093" 1/16 0.076 Brass Bright Tin-Lead NO
10-918-3-01
10-918-3-01
10-918-3-01
0.433" 0.040 - Swage Mount 0.113" 3/32 0.043 Brass Silver YES
10-888-1-035
10-888-1-035
10-888-1-035
0.315" 0.023 - Swage Mount 0.065" 1/32 0.042 Brass Gold YES
10-509-5-095
10-509-5-095
10-509-5-095
0.852" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.204 Brass Hot Solder Dip NO
09-0310-2-088
09-0310-2-088
09-0310-2-088
0.240" - - Swage Mount 0.084" 1/16 0.043 Brass Bright Tin-Lead NO
10-605-1-01
10-605-1-01
10-605-1-01
0.415" - - Swage Mount 0.075" 1/32 0.090 Brass Silver YES
10-8015-2-088
10-8015-2-088
10-8015-2-088
0.457" 0.040 TURRET/PIN Swage Mount 0.082" 1/16 0.076 Brass Bright Tin-Lead NO
10-861-2-04
10-861-2-04
10-861-2-04
0.266" 0.040 - Swage Mount 0.094" 1/16 0.094 Brass Electro-Tin YES
10-606-2-01
10-606-2-01
10-606-2-01
0.421" - - Swage Mount 0.105" 1/16 0.094 Brass Silver YES
10-542-6-01
10-542-6-01
10-542-6-01
0.582" - TURRET/DOUBLE TURRET Swage Mount 0.219" 3/16 0.094 Brass Silver YES
10-137-2A-05
10-137-2A-05
10-137-2A-05
0.258" - - Swage Mount 0.099" 1/16 0.094 Brass Electro Solder NO
10-502-1-04
10-502-1-04
10-502-1-04
0.319" - TURRET/DOUBLE TURRET Swage Mount 0.051" 1/32 0.076 Brass Electro-Tin YES
09-8055-1-044
09-8055-1-044
09-8055-1-044
0.651" 0.0305 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-221-2-01
10-221-2-01
10-221-2-01
0.297" - - Swage Mount 0.084" 1/16 0.076 Brass Silver YES
09-8836-1-044
09-8836-1-044
09-8836-1-044
0.760" 0.040 - Swage Mount 0.053" 1/32 0.043 Brass Bright Tin YES
10-415-3-044
10-415-3-044
10-415-3-044
0.279" - - Swage Mount 0.113" 3/32 0.052 Brass Bright Tin YES
