Commercial
Non-Insulated
Terminals

Filter
10-115-1-044
10-115-1-044
10-115-1-044
0.176" - - Swage Mount 0.051" 1/32 0.037 Brass Bright Tin YES
10-549-2-01
10-549-2-01
10-549-2-01
0.784" - Double Turret/Double Turret Swage Mount 0.105" 1/16 0.206 Brass Silver YES
10-533-2-05
10-533-2-05
10-533-2-05
0.351" - Turret/Turret Swage Mount 0.105" 1/16 0.094 Brass Electro Solder NO
10-408-2-05
10-408-2-05
10-408-2-05
0.417" - - Swage Mount 0.105" 1/16 0.116 Brass Electro Solder NO
10-801-4-05
10-801-4-05
10-801-4-05
0.473" 0.040 TURRET/PIN Swage Mount 0.145" 1/8 0.076 Brass Electro Solder NO
09-0164-3-05
09-0164-3-05
09-0164-3-05
0.371" - - Swage Mount 0.121" 3/32 0.125 Brass Electro Solder NO
10-846-3-05
10-846-3-05
10-846-3-05
0.463" - - Swage Mount 0.135" 3/32 0.116 Brass Electro Solder NO
10-846-6-05
10-846-6-05
10-846-6-05
0.558" - - Swage Mount 0.230" 3/16 0.116 Brass Electro Solder NO
10-402-2-05
10-402-2-05
10-402-2-05
0.453" - - Swage Mount 0.109" 1/16 0.116 Brass Electro Solder NO
10-204-6-05
10-204-6-05
10-204-6-05
0.593" - - Swage Mount 0.234" 3/16 0.116 Brass Electro Solder NO
09-0008-1-05
09-0008-1-05
09-0008-1-05
0.900" 0.030 - Solder 0.188" 3/32 0.043 Brass Electro Solder NO
09-8420-2-05
09-8420-2-05
09-8420-2-05
0.150" 0.040 - Solder - - 0.042 Brass Electro Solder NO
10-806-1-088
10-806-1-088
10-806-1-088
0.505" - - Swage Mount 0.078" 1/32 0.094 Brass Bright Tin-Lead NO
10-110-3-05
10-110-3-05
10-110-3-05
0.369" - - Swage Mount 0.135" 3/32 0.116 Brass Electro Solder NO
10-212-1-05
10-212-1-05
10-212-1-05
0.341" - - Swage Mount 0.075" 1/32 0.116 Brass Electro Solder NO
10-8015-6-05
10-8015-6-05
10-8015-6-05
0.582" 0.040 TURRET/PIN Swage Mount 0.207" 3/16 0.076 Brass Electro Solder NO
10-808-1-088
10-808-1-088
10-808-1-088
0.549" - - Swage Mount 0.078" 1/32 0.094 Brass Bright Tin-Lead NO
09-0049-2-05
09-0049-2-05
09-0049-2-05
0.296" - - Press Fit/Solder 0.078" 1/16 0.073 Brass Electro Solder NO
10-401-2-088
10-401-2-088
10-401-2-088
0.250" - - Swage Mount 0.094" 1/16 0.067 Brass Bright Tin-Lead NO
10-207-3-04
10-207-3-04
10-207-3-04
0.369" - - Swage Mount 0.135" 3/32 0.094 Brass Electro-Tin YES
