Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
10-423-3-035	0.378"	-	-	Swage Mount	0.135"	3/32	0.094	Brass	Gold	YES
10-311-4-035	0.484"	-	-	Swage Mount	0.172"	1/8	0.116	Brass	Gold	YES
09-0206-1-035	0.350"	-	-	Solder	-	-	-	Brass	Gold	YES
10-532-6-035	0.698"	-	Double Turret/Double Turret	Swage Mount	0.230"	3/16	0.159	Brass	Gold	YES
09-8046-3-035	0.388"	0.020	-	Swage Mount	0.113"	3/32	0.043	Brass	Gold	YES
09-8056-2-035	0.245"	0.020	-	Swage Mount	0.085"	1/16	0.031	Brass	Gold	YES
10-318-3-035	0.463"	-	-	Swage Mount	0.135"	3/32	0.116	Brass	Gold	YES
10-812-8-035	0.781"	-	Turret/Turret	Swage Mount	0.281"	1/4	0.147	Brass	Gold	YES
10-323-5-035	0.334"	-	-	Swage Mount	0.178"	5/32	0.076	Brass	Gold	YES
09-8067-1-035	0.771"	0.0405	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8356-2-035	0.332"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Gold	YES
10-301-1-035	0.249"	-	-	Swage Mount	0.062"	1/32	0.076	Brass	Gold	YES
10-532-5-035	0.663"	-	Double Turret/Double Turret	Swage Mount	0.195"	5/32	0.159	Brass	Gold	YES
10-426-3-035	0.354"	-	-	Swage Mount	0.135"	3/32	0.094	Brass	Gold	YES
10-301-2-035	0.281"	-	-	Swage Mount	0.094"	1/16	0.076	Brass	Gold	YES
09-8831-1-035	0.317"	0.090	-	Swage Mount	0.075"	1/32	0.094	Brass	Gold	YES
10-8015-2-035	0.457"	0.040	TURRET/PIN	Swage Mount	0.082"	1/16	0.076	Brass	Gold	YES
09-8850-1-035	0.196"	0.020	-	Swage Mount	0.051"	1/32	0.035	Brass	Gold	YES
09-0118-1-035	0.153"	-	-	Swage Mount	0.053"	1/32	0.033	Brass	Gold	YES
09-0118-2-035	0.184"	-	-	Swage Mount	0.084"	1/16	0.033	Brass	Gold	YES
