Commercial
Non-Insulated
Terminals

Filter
10-483-4-088
10-483-4-088
10-483-4-088
0.493" - - Swage Mount 0.165" 1/8 0.116 Brass Bright Tin-Lead NO
10-110-4-044
10-110-4-044
10-110-4-044
0.399" - - Swage Mount 0.165" 1/8 0.116 Brass Bright Tin YES
10-875-1-03
10-875-1-03
10-875-1-03
0.151" 0.025 - Swage Mount 0.051" 1/32 0.052 Brass Gold YES
10-806-4-03
10-806-4-03
10-806-4-03
0.599" - - Swage Mount 0.172" 1/8 0.094 Brass Gold YES
10-832-4-03
10-832-4-03
10-832-4-03
0.406" 0.050 - Swage Mount 0.156" 1/8 0.064 Brass Gold YES
10-932-3-03
10-932-3-03
10-932-3-03
0.281" - - Swage Mount 0.125" 3/32 0.0635 Brass Gold YES
10-206-3-044
10-206-3-044
10-206-3-044
0.306" - - Swage Mount 0.115" 3/32 0.076 Brass Bright Tin YES
09-6007-1-088
09-6007-1-088
09-6007-1-088
0.555" 0.025 SQ. - Press Fit/Solder 0.080" 1/16 0.055 Brass Bright Tin-Lead NO
09-8835-1-088
09-8835-1-088
09-8835-1-088
0.725" 0.040 (+0.002/-0.001) - Solder 0.100" 1/16 0.043 Brass Bright Tin-Lead NO
09-0036-2-088
09-0036-2-088
09-0036-2-088
0.250" - - Swage Mount 0.094" 1/16 0.067 Brass Bright Tin-Lead NO
10-441-1-04
10-441-1-04
10-441-1-04
0.419" - - Swage Mount 0.075" 1/32 0.1405 Brass Electro-Tin YES
10-460-1-04
10-460-1-04
10-460-1-04
0.334" - - Swage Mount 0.053" 1/32 0.063 Brass Electro-Tin YES
10-421-3-044
10-421-3-044
10-421-3-044
0.604" - - Swage Mount 0.135" 3/32 0.116 Brass Bright Tin YES
10-240-3-04
10-240-3-04
10-240-3-04
0.499" - - Swage Mount 0.135" 3/32 0.116 Brass Electro-Tin YES
10-209-6-04
10-209-6-04
10-209-6-04
0.453" - - Swage Mount 0.234" 3/16 0.094 Brass Electro-Tin YES
09-8154-1-05
09-8154-1-05
09-8154-1-05
0.674" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Electro Solder NO
09-6004-1-05
09-6004-1-05
09-6004-1-05
1.034" 0.045 SQ. TURRET/SQUARE-WRAP PC PIN Press Fit/Solder 0.094" 1/16 0.055 Brass Electro Solder NO
10-8025-2-05
10-8025-2-05
10-8025-2-05
0.379" 0.040 TURRET/PIN Swage Mount 0.082" 1/16 0.076 Brass Electro Solder NO
09-8035-1-088
09-8035-1-088
09-8035-1-088
1.125" 0.0625 - - - - - Brass Bright Tin-Lead NO
09-8563-1-035
09-8563-1-035
09-8563-1-035
0.282" 0.020 - Solder 0.260" 15/64 0.024 Beryllium Copper Gold YES
