Commercial
Insulated
Pin Terminals

Filter
1107-09-0318
1107-09-0318
1107-09-0318
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Gray NO
1151R-09-0318
1151R-09-0318
1151R-09-0318
0.390" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Gray NO
1107-09-0317
1107-09-0317
1107-09-0317
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Violet YES
1107-09-0313
1107-09-0313
1107-09-0313
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Orange NO
1107-09-0312
1107-09-0312
1107-09-0312
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Red NO
1151R-09-0316
1151R-09-0316
1151R-09-0316
0.390" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
1178R-09-0416
1178R-09-0416
1178R-09-0416
0.445" 0.035 Pin/Slotted PRESS LOCK 1/32 - 1/16 0.086 Brass Electro-Tin - - PTFE Blue YES
1135-09-0411
1135-09-0411
1135-09-0411
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Brown NO
1135-09-0417
1135-09-0417
1135-09-0417
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Violet YES
1135-09-0418
1135-09-0418
1135-09-0418
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Electro-Tin - - PTFE Gray NO
1135-09-0317
1135-09-0317
1135-09-0317
0.400" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Gold - - PTFE Violet YES
1100R-09-04415
1100R-09-04415
1100R-09-04415
0.350" 0.040 - Press Fit 3/32 0.098 Brass Bright Tin - - PTFE Green YES
1131-09-0411
1131-09-0411
1131-09-0411
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Brown NO
1107-09-04416
1107-09-04416
1107-09-04416
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.158 Brass Bright Tin - - PTFE Blue YES
1111R-09-04411
1111R-09-04411
1111R-09-04411
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Bright Tin - - PTFE Brown NO
1127-09-04417
1127-09-04417
1127-09-04417
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Violet YES
1127-09-0415
1127-09-0415
1127-09-0415
1.103" 0.070 - 4-40 Nut 3/32 0.120 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Green YES
1112-09-0413
1112-09-0413
1112-09-0413
0.293" - - Press Fit 1/64 0.113 Brass Electro-Tin - - PTFE Orange NO
1111R-09-0319
1111R-09-0319
1111R-09-0319
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE White YES
1111R-09-0316
1111R-09-0316
1111R-09-0316
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Blue YES
