Commercial
Insulated
Pin Terminals

Filter
1175-441-0313
1175-441-0313
1175-441-0313
0.548" - TURRET/SLOTTED PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Gold - - PTFE Orange NO
1175-441-0514
1175-441-0514
1175-441-0514
0.548" - TURRET/SLOTTED PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Electro Solder - - PTFE Yellow NO
1154-43-08812
1154-43-08812
1154-43-08812
1.197" 0.050 Pin/Slotted Press Fit 11/32 0.158 Brass Bright Tin-Lead - - PTFE Red NO
1175-423-04416
1175-423-04416
1175-423-04416
0.725" - Double Turret/Double Turret PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Blue YES
1175-423-04414
1175-423-04414
1175-423-04414
0.725" - Double Turret/Double Turret PRESS LOCK 3/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Yellow NO
1175-422-04417
1175-422-04417
1175-422-04417
0.693" - Double Turret/Double Turret PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Violet YES
1111-42-08812
1111-42-08812
1111-42-08812
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 3/16 0.172 Brass Bright Tin-Lead - - PTFE Red NO
1111-42-08814
1111-42-08814
1111-42-08814
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 3/16 0.172 Brass Bright Tin-Lead - - PTFE Yellow NO
1175-414-04417
1175-414-04417
1175-414-04417
0.642" - DOUBLE Turret/Turret PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Violet YES
1175-414-04413
1175-414-04413
1175-414-04413
0.642" - DOUBLE Turret/Turret PRESS LOCK 1/8 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Orange NO
1130R-07-0116
1130R-07-0116
1130R-07-0116
2.083" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Silver - - PTFE Blue YES
1127-01-04413
1127-01-04413
1127-01-04413
0.594" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Orange YES
1169-37-08812
1169-37-08812
1169-37-08812
0.750" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Bright Tin-Lead Brass DIALLYL PHTHALATE Red NO
1169-37-0418
1169-37-0418
1169-37-0418
0.750" - - 4-40 Nut 1/8 0.120 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1169-37-08813
1169-37-08813
1169-37-08813
0.750" - - 4-40 Nut 1/8 0.120 Brass Bright Tin-Lead Bright Tin-Lead Brass DIALLYL PHTHALATE Orange NO
1169-37-0416
1169-37-0416
1169-37-0416
0.750" - - 4-40 Nut 1/8 0.120 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Blue YES
1105-10-08812
1105-10-08812
1105-10-08812
0.705" - Double Turret/Double Turret Press Fit Up to 3/16 0.204 Brass Bright Tin-Lead - - PTFE Red NO
1111-15-08815
1111-15-08815
1111-15-08815
0.609" 0.040 DOUBLE Turret/Tip Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1125-15-08816
1125-15-08816
1125-15-08816
0.578" - - 4-40 Nut 7/64 0.120 Brass Bright Tin-Lead Electro-Tin Brass PTFE Blue NO
1111-14S-0315
1111-14S-0315
1111-14S-0315
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Gold - - PTFE Green YES
