Commercial
Insulated
Pin Terminals

Filter
1106-04-0514
1106-04-0514
1106-04-0514
0.540" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Yellow NO
1177-04-0415
1177-04-0415
1177-04-0415
0.400" 0.040 - PRESS LOCK 1/16 - 3/32 0.136 Brass Electro-Tin - - PTFE Green YES
1103R-04-0114
1103R-04-0114
1103R-04-0114
0.382" - - Press Fit 1/16 0.136 Brass Silver - - PTFE Yellow NO
1106-04-0512
1106-04-0512
1106-04-0512
0.540" - - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Red NO
1156-04-0410
1156-04-0410
1156-04-0410
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Electro-Tin - - PTFE Black YES
1112R-04-0314
1112R-04-0314
1112R-04-0314
0.200" - - Press Fit 1/32 0.111 Brass Gold - - PTFE Yellow NO
1131-04-0119
1131-04-0119
1131-04-0119
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Silver - - PTFE White YES
1103R-04-0313
1103R-04-0313
1103R-04-0313
0.382" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Orange NO
1131-04-0114
1131-04-0114
1131-04-0114
0.562" 0.050 Pin/Tip Press Fit 3/32 0.172 Brass Silver - - PTFE Yellow NO
1156-04-0413
1156-04-0413
1156-04-0413
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Electro-Tin - - PTFE Orange NO
1156-04-0414
1156-04-0414
1156-04-0414
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.136 Brass Electro-Tin - - PTFE Yellow NO
1123-04-08810
1123-04-08810
1123-04-08810
0.947" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Black NO
1177-58-04416
1177-58-04416
1177-58-04416
0.730" 0.050 Pin/Pin PRESS LOCK 1/32 - 1/16 0.136 Brass Bright Tin - - PTFE Blue YES
1123-04-08811
1123-04-08811
1123-04-08811
0.947" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Brown NO
1123-04-08816
1123-04-08816
1123-04-08816
0.947" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Blue NO
1123-04-08817
1123-04-08817
1123-04-08817
0.947" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Bright Tin-Lead - - PTFE Violet NO
1107-04-0412
1107-04-0412
1107-04-0412
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Red NO
1107-04-0414
1107-04-0414
1107-04-0414
0.819" 0.040 Pin/Pin Press Fit Up to 3/16 0.136 Brass Electro-Tin - - PTFE Yellow NO
1130-04-0519
1130-04-0519
1130-04-0519
0.906" (0.030)/(0.050) Pin/Pin Press Fit Up to 1/4 0.172 Brass Electro Solder - - PTFE White NO
1103R-04-0311
1103R-04-0311
1103R-04-0311
0.382" - - Press Fit 1/16 0.136 Brass Gold - - PTFE Brown NO
