Non-Insulated
PC Jacks

Filter
09-9743-1-088
09-9743-1-088
09-9743-1-088
0.032 - 0.046 0.210 " 0.260" - Press Fit/Solder - 1/16 - 5/32 0.073 Brass Bright Tin-Lead Vertical
09-9293-1-035
09-9293-1-035
09-9293-1-035
0.060 0.304 " 0.350" - Press Fit/Solder - 1/16 - 3/16 0.128 (+0.001/-0.002) Brass Gold Vertical
09-9742-1-088
09-9742-1-088
09-9742-1-088
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 3/32 - 1/8 0.089 Brass Bright Tin-Lead Vertical
09-9742-1-06
09-9742-1-06
09-9742-1-06
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 3/32 - 1/8 0.089 Brass Electro-Tin Vertical
09-9742-1-04
09-9742-1-04
09-9742-1-04
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 3/32 - 1/8 0.089 Brass Electro-Tin Vertical
09-9293-1-04
09-9293-1-04
09-9293-1-04
0.060 0.304 " 0.350" - Press Fit/Solder - 1/16 - 3/16 0.128 (+0.001/-0.002) Brass Electro-Tin Vertical
09-9711-1-03
09-9711-1-03
09-9711-1-03
0.016 - 0.020 0.126 " 0.138" - Solder - 1/32 - 3/32 0.043 Brass Gold Vertical
09-9742-1-03
09-9742-1-03
09-9742-1-03
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 3/32 - 1/8 0.089 Brass Gold Vertical
09-9741-1-063
09-9741-1-063
09-9741-1-063
0.032 - 0.046 0.495 " 0.655" Jack/Pin Press Fit/Solder - 1/16 - 3/8 0.090 Brass Bright Tin-Lead Vertical
09-9169-1-063
09-9169-1-063
09-9169-1-063
0.030 0.190 " 0.206" - Press Fit/Solder - 3/32 - 5/32 0.076 Brass Bright Tin-Lead Vertical
09-9169-1-088
09-9169-1-088
09-9169-1-088
0.030 0.190 " 0.206" - Press Fit/Solder - 3/32 - 5/32 0.076 Brass Bright Tin-Lead Vertical
09-9617-1-035
09-9617-1-035
09-9617-1-035
0.022 - 0.034 0.140 " 0.210" - Press Fit/Solder - 1/16 - 5/32 0.078 Brass Gold Vertical
09-9603-4-088
09-9603-4-088
09-9603-4-088
0.032 - 0.046 0.200 " 0.432" Jack/Slotted Swage Mount 0.156" 1/8 0.129 Brass Bright Tin-Lead Vertical
09-9037-2-04
09-9037-2-04
09-9037-2-04
0.030 - 0.032 0.183 " 0.390" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9741-1-06
09-9741-1-06
09-9741-1-06
0.032 - 0.046 0.495 " 0.655" Jack/Pin Press Fit/Solder - 1/16 - 3/8 0.090 Brass Electro-Tin Vertical
09-9051-3-035
09-9051-3-035
09-9051-3-035
0.016 - 0.020 0.210 " 0.287" Jack/Turret Swage Mount 0.104" 3/32 0.076 Brass Gold Vertical
09-9617-1-063
09-9617-1-063
09-9617-1-063
0.022 - 0.034 0.140 " 0.210" - Press Fit/Solder - 1/16 - 5/32 0.078 Brass Bright Tin-Lead Vertical
09-9732-1-035
09-9732-1-035
09-9732-1-035
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Gold Vertical
09-9739-1-04
09-9739-1-04
09-9739-1-04
0.032 - 0.046 0.205 " 0.385" Jack/Pin Press Fit/Solder - 3/32 - 3/16 0.090 Brass Electro-Tin Vertical
09-9039-1-04
09-9039-1-04
09-9039-1-04
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Electro-Tin Vertical
