Military
Non-Insulated
Terminals

Filter
15R-903-3-088
15R-903-3-088
15R-903-3-088
0.313" - Swage Mount 0.125" 3/32 0.0635 Phosphor Bronze Bright Tin-Lead M55155/24XD03 AA59126/24XD03
15R-904-4-05
15R-904-4-05
15R-904-4-05
0.292" - Swage Mount 0.156" 1/8 0.0635 Phosphor Bronze Electro Solder M55155/25XB04 AA59126/25XB04
15R-904-4-095
15R-904-4-095
15R-904-4-095
0.292" - Swage Mount 0.156" 1/8 0.0635 Phosphor Bronze Hot Solder Dip M55155/25XC04 AA59126/25XC04
15R-904-4-088
15R-904-4-088
15R-904-4-088
0.292" - Swage Mount 0.156" 1/8 0.0635 Phosphor Bronze Bright Tin-Lead M55155/25XD04 AA59126/25XD04
15R-904-2-05
15R-904-2-05
15R-904-2-05
0.230" - Swage Mount 0.094" 1/16 0.0635 Phosphor Bronze Electro Solder M55155/25XB02 AA59126/25XB02
15R-904-1-095
15R-904-1-095
15R-904-1-095
0.198" - Swage Mount 0.062" 1/32 0.0635 Phosphor Bronze Hot Solder Dip M55155/25XC01 AA59126/25XC01
15R-904-3-095
15R-904-3-095
15R-904-3-095
0.261" - Swage Mount 0.125" 3/32 0.0635 Phosphor Bronze Hot Solder Dip M55155/25XC03 AA59126/25XC03
15R-905-1-095
15R-905-1-095
15R-905-1-095
0.250" - Swage Mount 0.062" 1/32 0.0635 Phosphor Bronze Hot Solder Dip M55155/23XC01 AA59126/23XC01
15R-905-2-095
15R-905-2-095
15R-905-2-095
0.282" - Swage Mount 0.094" 1/16 0.0635 Phosphor Bronze Hot Solder Dip M55155/23XC02 AA59126/23XC02
15R-905-4-088
15R-905-4-088
15R-905-4-088
0.344" - Swage Mount 0.156" 1/8 0.0635 Phosphor Bronze Bright Tin-Lead M55155/23XD04 AA59126/23XD04
15R-905-4-095
15R-905-4-095
15R-905-4-095
0.344" - Swage Mount 0.156" 1/8 0.0635 Phosphor Bronze Hot Solder Dip M55155/23XC04 AA59126/23XC04
15R-905-1-088
15R-905-1-088
15R-905-1-088
0.250" - Swage Mount 0.062" 1/32 0.0635 Phosphor Bronze Bright Tin-Lead M55155/23XD01 AA59126/23XD01
15R-905-3-05
15R-905-3-05
15R-905-3-05
0.313" - Swage Mount 0.125" 3/32 0.0635 Phosphor Bronze Electro Solder M55155/23XB03 AA59126/23XB03
15-903-4-05
15-903-4-05
15-903-4-05
0.344" - Swage Mount 0.156" 1/8 0.0635 Brass Electro Solder M55155/24XH04 AA59126/24XH04
15R-493-2-05
15R-493-2-05
15R-493-2-05
0.209" - Swage Mount 0.084" 1/16 0.0635 Phosphor Bronze Electro Solder M55155/24XB07 AA59126/24XB07
09-0016-1M-05
09-0016-1M-05
09-0016-1M-05
0.280" - 6-32 Screw - - CLEARANCE FOR #6 Screw Brass Electro Solder M55155/26XH03 AA59126/26XH03
15-142-11-088
15-142-11-088
15-142-11-088
0.131" - Swage Mount 0.037" 1/64 0.043 Brass Bright Tin-Lead M55155/11XJ08 AA59126/11XJ08
15-209-8-088
15-209-8-088
15-209-8-088
0.514" - Swage Mount 0.296" 1/4 0.094 Brass Bright Tin-Lead M55155/30XJ20 AA59126/30XJ20
15-142-1-095
15-142-1-095
15-142-1-095
0.147" - Swage Mount 0.053" 1/32 0.043 Brass Hot Solder Dip M55155/11XI09 AA59126/11XI09
15-141-3-095
15-141-3-095
15-141-3-095
0.209" - Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip M55155/11XI06 AA59126/11XI06
