Commercial
Non-Insulated
Terminals

Filter
09-7181-3-044
09-7181-3-044
09-7181-3-044
0.259" - - RIVET MOUNT 0.114" 3/32 0.036 Brass Bright Tin YES
09-7128-1-04
09-7128-1-04
09-7128-1-04
0.782" 0.0405 - RIVET MOUNT 0.056" 1/32 0.044 Brass Electro-Tin YES
09-7145-3-088
09-7145-3-088
09-7145-3-088
0.313" 0.030 - RIVET MOUNT 0.120" 3/32 0.048 Brass Bright Tin-Lead NO
09-7148-2-03
09-7148-2-03
09-7148-2-03
0.442" 0.040 - RIVET MOUNT 0.104" 1/16 0.048 Brass Gold YES
09-7171-2-05
09-7171-2-05
09-7171-2-05
0.235" - - RIVET MOUNT 0.082" 1/16 0.035 Brass Electro Solder NO
09-7127-1-088
09-7127-1-088
09-7127-1-088
0.674" 0.0405 - RIVET MOUNT 0.056" 1/32 0.044 Brass Bright Tin-Lead NO
09-7167-2-088
09-7167-2-088
09-7167-2-088
0.558" 0.125 - RIVET MOUNT 0.110" 1/16 0.090 Brass Bright Tin-Lead NO
09-7117-2-04
09-7117-2-04
09-7117-2-04
0.516" 0.030 - RIVET MOUNT 0.083" 1/16 0.035 Brass Electro-Tin YES
10-415-3-035
10-415-3-035
10-415-3-035
0.279" - - Swage Mount 0.113" 3/32 0.052 Brass Gold YES
10-477-4-035
10-477-4-035
10-477-4-035
0.303" - - Swage Mount 0.147" 1/8 0.063 Brass Gold YES
09-8178-2-035
09-8178-2-035
09-8178-2-035
0.531" 0.025 - Swage Mount 0.094" 1/16 0.052 Brass Gold YES
09-7146-4-035
09-7146-4-035
09-7146-4-035
0.376" 0.030 - RIVET MOUNT 0.152" 1/8 0.048 Brass Gold YES
09-7170-1B-044
09-7170-1B-044
09-7170-1B-044
0.166" - - RIVET MOUNT 0.067" 3/64 0.035 Brass Bright Tin YES
09-7149-2-044
09-7149-2-044
09-7149-2-044
0.328" 0.045 - RIVET MOUNT 0.104" 1/16 0.048 Brass Bright Tin YES
09-7026-1-01
09-7026-1-01
09-7026-1-01
0.478" 0.026 - RIVET MOUNT 0.051" 1/32 0.035 Brass Silver YES
09-7181-3-05
09-7181-3-05
09-7181-3-05
0.259" - - RIVET MOUNT 0.114" 3/32 0.036 Brass Electro Solder NO
09-7152-2-01
09-7152-2-01
09-7152-2-01
0.213" 0.030 - RIVET MOUNT 0.093" 1/16 0.035 Brass Silver YES
09-7143-1-05
09-7143-1-05
09-7143-1-05
0.493" 0.040 - RIVET MOUNT 0.088" 1/16 0.044 Brass Electro Solder NO
09-7155-2-088
09-7155-2-088
09-7155-2-088
0.326" 0.058 - RIVET MOUNT 0.095" 1/16 0.060 Brass Bright Tin-Lead NO
09-7133-2-04
09-7133-2-04
09-7133-2-04
1.013" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Electro-Tin YES
