Commercial
Non-Insulated
Terminals

Filter
09-7010-4-035
09-7010-4-035
09-7010-4-035
0.291" 0.050 - Swage Mount 0.150" 1/8 0.055 Brass Gold YES
10-111-2-044
10-111-2-044
10-111-2-044
0.286" - - Swage Mount 0.105" 1/16 0.094 Brass Bright Tin YES
09-7010-2-05
09-7010-2-05
09-7010-2-05
0.235" 0.050 - Swage Mount 0.095" 1/16 0.055 Brass Electro Solder NO
09-8187-2-088
09-8187-2-088
09-8187-2-088
0.645" 0.020 - Solder 0.100" 1/64 TO 1/16 0.024 Brass Bright Tin-Lead NO
10-109-6-04
10-109-6-04
10-109-6-04
0.378" - - Swage Mount 0.219" 3/16 0.094 Brass Electro-Tin YES
10-107-3-088
10-107-3-088
10-107-3-088
0.218" - - Swage Mount 0.125" 3/32 0.067 Brass Bright Tin-Lead NO
09-0104-4-03
09-0104-4-03
09-0104-4-03
0.281" - - 4-40 - - 4-40 THREAD Brass Gold YES
09-0104-10-044
09-0104-10-044
09-0104-10-044
0.466" - - 4-40 - - 4-40 THREAD Brass Bright Tin YES
10-106-3-03
10-106-3-03
10-106-3-03
0.316" - - Swage Mount 0.135" 3/32 0.094 Brass Gold YES
09-0101-4-05
09-0101-4-05
09-0101-4-05
0.289" - - Swage Mount 0.130" 3/32 0.067 Brass Electro Solder NO
09-0088-3-035
09-0088-3-035
09-0088-3-035
0.406" - - Swage Mount 0.125" 3/32 0.159 Brass Gold YES
10-105-11-04
10-105-11-04
10-105-11-04
0.146" - - Swage Mount 0.037" 1/64 0.076 Brass Electro-Tin YES
09-8007-2-035
09-8007-2-035
09-8007-2-035
0.732" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Gold YES
10-105-1-05
10-105-1-05
10-105-1-05
0.162" - - Swage Mount 0.053" 1/32 0.076 Brass Electro Solder NO
10-415-6-05
10-415-6-05
10-415-6-05
0.373" - - Swage Mount 0.207" 3/16 0.052 Brass Electro Solder NO
10-416-11-035
10-416-11-035
10-416-11-035
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Gold YES
10-416-11-01
10-416-11-01
10-416-11-01
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Silver YES
10-416-2-035
10-416-2-035
10-416-2-035
0.240" - - Swage Mount 0.084" 1/16 0.064 Brass Gold YES
10-416-3-035
10-416-3-035
10-416-3-035
0.271" - - Swage Mount 0.115" 3/32 0.064 Brass Gold YES
10-417-8-088
10-417-8-088
10-417-8-088
0.688" - - Swage Mount 0.297" 1/4 0.116 Brass Bright Tin-Lead NO

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
