Commercial
Non-Insulated
Terminals

Filter
10-904-2-03
10-904-2-03
10-904-2-03
0.230" - - Swage Mount 0.094" 1/16 0.0635 Brass Gold YES
09-0208-2-095
09-0208-2-095
09-0208-2-095
0.267" - - Swage Mount 0.094" 1/16 0.067 LEADED Red Brass Hot Solder Dip NO
10-542-2-035
10-542-2-035
10-542-2-035
0.457" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.094 Brass Gold YES
09-0152-2-05
09-0152-2-05
09-0152-2-05
0.360" - - Swage Mount 0.090" 1/16 0.055 Brass Electro Solder NO
10-714-1-03
10-714-1-03
10-714-1-03
0.637" - DOUBLE TURRET/THREAD Swage Mount 0.075" 1/32 0.204 Brass Gold YES
10-8019-2-035
10-8019-2-035
10-8019-2-035
0.402" 0.025 - Swage Mount 0.082" 1/16 0.035 Brass Gold YES
10-459-5-035
10-459-5-035
10-459-5-035
0.334" - - Swage Mount 0.178" 5/32 0.064 Brass Gold YES
09-0078-11-035
09-0078-11-035
09-0078-11-035
0.193" - - Swage Mount 0.037" 1/64 0.076 Brass Gold YES
09-8768-11-035
09-8768-11-035
09-8768-11-035
0.195" 0.020 - Swage Mount 0.030" 1/64 0.028 Brass Gold YES
09-8631-1-035
09-8631-1-035
09-8631-1-035
0.704" 0.032 - Swage Mount 0.051" 1/32 0.055 Brass Gold YES
10-8019-1-035
10-8019-1-035
10-8019-1-035
0.371" 0.025 - Swage Mount 0.051" 1/32 0.035 Brass Gold YES
10-418-2-05
10-418-2-05
10-418-2-05
0.636" - Turret/Turret Swage Mount 0.105" 1/16 0.120 Brass Electro Solder NO
09-8134-2-05
09-8134-2-05
09-8134-2-05
0.340" 0.040 TURRET/PIN Swage Mount 0.082" 1/16 0.076 Brass Electro Solder NO
10-925-4-035
10-925-4-035
10-925-4-035
0.311" 0.025 - Swage Mount 0.156" 1/8 0.0625 Brass Gold YES
10-913-2-035
10-913-2-035
10-913-2-035
0.200" 0.059 - Swage Mount 0.090" 1/16 0.0635 Brass Gold YES
10-503-6-05
10-503-6-05
10-503-6-05
0.457" - Double Turret/Double Turret Swage Mount 0.207" 3/16 0.076 Brass Electro Solder NO
09-0254-2-05
09-0254-2-05
09-0254-2-05
0.350" - TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.081 Brass Electro Solder NO
09-8632-1-035
09-8632-1-035
09-8632-1-035
0.794" 0.032 - Swage Mount 0.051" 1/32 0.055 Brass Gold YES
10-220-11-035
10-220-11-035
10-220-11-035
0.193" - - Swage Mount 0.037" 1/64 0.064 Brass Gold YES
09-8843-1-035
09-8843-1-035
09-8843-1-035
0.335" 0.0305 - Swage Mount 0.051" 1/32 0.042 Brass Gold YES
