Commercial
Non-Insulated
Terminals

Filter
10-120-2-04
10-120-2-04
10-120-2-04
0.250" - - Swage Mount 0.094" 1/16 0.052 Brass Electro-Tin YES
09-0178-2-04
09-0178-2-04
09-0178-2-04
0.238" - - Swage Mount 0.082" 1/16 0.052 Brass Electro-Tin YES
09-0178-2-088
09-0178-2-088
09-0178-2-088
0.238" - - Swage Mount 0.082" 1/16 0.052 Brass Bright Tin-Lead NO
10-129-2-01
10-129-2-01
10-129-2-01
0.205" - - Press Fit/Solder 0.100" 1/16 0.055 Brass Silver YES
10-129-2-03
10-129-2-03
10-129-2-03
0.205" - - Press Fit/Solder 0.100" 1/16 0.055 Brass Gold YES
10-969-2-044
10-969-2-044
10-969-2-044
0.269" 0.050 - Swage Mount 0.082" 1/16 0.055 Brass Bright Tin YES
10-969-2-088
10-969-2-088
10-969-2-088
0.269" 0.050 - Swage Mount 0.082" 1/16 0.055 Brass Bright Tin-Lead NO
10-969-2-035
10-969-2-035
10-969-2-035
0.269" 0.050 - Swage Mount 0.082" 1/16 0.055 Brass Gold YES
10-969-2-04
10-969-2-04
10-969-2-04
0.269" 0.050 - Swage Mount 0.082" 1/16 0.055 Brass Electro-Tin YES
09-0304-1-01
09-0304-1-01
09-0304-1-01
0.154" - - Swage Mount 0.060" 1/32 0.055 Brass Silver YES
09-0298-1-04
09-0298-1-04
09-0298-1-04
0.344" 0.050 - Press Fit/Solder 0.055" 1/16 0.055 Brass Electro-Tin YES
09-8188-1-088
09-8188-1-088
09-8188-1-088
0.137" 0.025 - Swage Mount 0.047" 1/32 0.035 Brass Bright Tin-Lead NO
09-8188-1-035
09-8188-1-035
09-8188-1-035
0.137" 0.025 - Swage Mount 0.047" 1/32 0.035 Brass Gold YES
09-0363-1-01
09-0363-1-01
09-0363-1-01
0.315" 0.025 - Press Fit/Solder 0.128" 1/16 TO 3/32 0.055 Brass Silver YES
09-7115-2-044
09-7115-2-044
09-7115-2-044
0.297" 0.030 - RIVET MOUNT 0.083" 1/16 0.035 Brass Bright Tin YES
09-7120-1-044
09-7120-1-044
09-7120-1-044
0.268" 0.020 - RIVET MOUNT 0.052" 1/32 0.035 Brass Bright Tin YES
10-461-4-01
10-461-4-01
10-461-4-01
0.459" - - Swage Mount 0.147" 1/8 0.043 Brass Silver YES
09-8400-3-035
09-8400-3-035
09-8400-3-035
0.530" 0.040 - Swage Mount 0.110" 1/16 0.043 Brass Gold YES
09-7186-1A-088
09-7186-1A-088
09-7186-1A-088
0.191" - - RIVET MOUNT 0.041" 1/64 0.044 Brass Bright Tin-Lead NO
10-823-2-05
10-823-2-05
10-823-2-05
0.564" 0.037 (TAPER) DOUBLE TURRET/TAPER PIN Swage Mount 0.087" 1/16 0.120 Brass Electro Solder NO

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
