Commercial
Non-Insulated
Terminals

Filter
09-7155-2-088
09-7155-2-088
09-7155-2-088
0.326" 0.058 - RIVET MOUNT 0.095" 1/16 0.060 Brass Bright Tin-Lead NO
09-7133-2-04
09-7133-2-04
09-7133-2-04
1.013" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Electro-Tin YES
09-7147-2-044
09-7147-2-044
09-7147-2-044
0.219" 0.030 - RIVET MOUNT 0.089" 1/16 0.048 Brass Bright Tin YES
09-7184-2B-044
09-7184-2B-044
09-7184-2B-044
0.309" - - RIVET MOUNT 0.097" 9/128 0.044 Brass Bright Tin YES
09-7170-1B-01
09-7170-1B-01
09-7170-1B-01
0.166" - - RIVET MOUNT 0.067" 3/64 0.035 Brass Silver YES
09-7166-2-035
09-7166-2-035
09-7166-2-035
0.337" 0.040 - RIVET MOUNT 0.103" 1/16 0.076 Brass Gold YES
10-906-2-035
10-906-2-035
10-906-2-035
0.230" - - Swage Mount 0.094" 1/16 0.0635 Brass Gold YES
09-7178-2-05
09-7178-2-05
09-7178-2-05
0.544" - - RIVET MOUNT 0.123" 1/16 0.116 Brass Electro Solder NO
09-7138-4-088
09-7138-4-088
09-7138-4-088
0.690" 0.040 (+0.000/-0.004) - RIVET MOUNT 0.165" 1/8 0.044 Brass Bright Tin-Lead NO
09-8094-2A-035
09-8094-2A-035
09-8094-2A-035
0.182" 0.025 - Swage Mount 0.082" 1/16 0.035 Brass Gold YES
09-7132-2-04
09-7132-2-04
09-7132-2-04
0.853" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Electro-Tin YES
09-7101-2-044
09-7101-2-044
09-7101-2-044
0.489" 0.040 - RIVET MOUNT 0.087" 1/16 0.043 Brass Bright Tin YES
09-7135-2-035
09-7135-2-035
09-7135-2-035
0.483" 0.040 - RIVET MOUNT 0.087" 1/16 0.044 Brass Gold YES
09-7145-3-044
09-7145-3-044
09-7145-3-044
0.313" 0.030 - RIVET MOUNT 0.120" 3/32 0.048 Brass Bright Tin YES
09-7144-1-04
09-7144-1-04
09-7144-1-04
0.238" 0.027 (+0.000/-0.003) - RIVET MOUNT 0.114" 3/32 0.035 Brass Electro-Tin YES
09-8777-2-095
09-8777-2-095
09-8777-2-095
0.215" 0.020 - Swage Mount 0.085" 1/16 0.031 Brass Hot Solder Dip NO
09-7193-2-044
09-7193-2-044
09-7193-2-044
0.494" - - RIVET MOUNT 0.125" 1/16 0.116 Brass Bright Tin YES
09-7161-1-088
09-7161-1-088
09-7161-1-088
0.252" 0.040 - RIVET MOUNT 0.064" 1/32 0.0625 Brass Bright Tin-Lead NO
10-117-11-035
10-117-11-035
10-117-11-035
0.131" - - Swage Mount 0.037" 1/64 0.067 Brass Gold YES
09-7134-2-035
09-7134-2-035
09-7134-2-035
1.093" 0.0405 - RIVET MOUNT 0.087" 1/16 0.044 Brass Gold YES
