Commercial
Non-Insulated
Terminals

Filter
10-109-3-04
10-109-3-04
10-109-3-04
0.284" - - Swage Mount 0.125" 3/32 0.094 Brass Electro-Tin YES
09-0269-2-04
09-0269-2-04
09-0269-2-04
0.265" - - Press Fit/Solder 0.130" 1/16 TO 3/32 0.055 Brass Electro-Tin YES
10-508-1-04
10-508-1-04
10-508-1-04
0.506" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.206 Brass Electro-Tin YES
10-543-2-04
10-543-2-04
10-543-2-04
0.539" - Double Turret/Double Turret Swage Mount 0.094" 1/16 0.094 Brass Electro-Tin YES
10-492-3-04
10-492-3-04
10-492-3-04
0.416" - Slotted/Slotted Swage Mount 0.135" 3/32 0.120 Brass Electro-Tin YES
10-266-1-04
10-266-1-04
10-266-1-04
0.209" - - Swage Mount 0.053" 1/32 0.206 Brass Electro-Tin YES
10-301-3-044
10-301-3-044
10-301-3-044
0.312" - - Swage Mount 0.125" 3/32 0.076 Brass Bright Tin YES
09-0174-1-04
09-0174-1-04
09-0174-1-04
0.205" - - Press Fit/Solder 0.158" 3/32 0.094 Brass Electro-Tin YES
09-0264-2-04
09-0264-2-04
09-0264-2-04
0.350" 0.040 DOUBLE TURRET/PIN Swage Mount 0.084" 1/16 0.076 Brass Electro-Tin YES
09-0254-2-04
09-0254-2-04
09-0254-2-04
0.350" - TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.081 Brass Electro-Tin YES
10-512-4-04
10-512-4-04
10-512-4-04
0.536" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.129 Brass Electro-Tin YES
10-514-3-04
10-514-3-04
10-514-3-04
0.375" - Turret/Turret Swage Mount 0.135" 3/32 0.129 Brass Electro-Tin YES
10-870-4-04
10-870-4-04
10-870-4-04
0.459" 0.030 - Swage Mount 0.147" 1/8 0.067 Brass Electro-Tin YES
10-215-2-04
10-215-2-04
10-215-2-04
0.238" - - Swage Mount 0.084" 1/16 0.063 Brass Electro-Tin YES
09-8025-1-04
09-8025-1-04
09-8025-1-04
0.235" 0.040 - Swage Mount 0.045" 1/64 0.043 Brass Electro-Tin YES
09-0168-3-04
09-0168-3-04
09-0168-3-04
0.453" - - Swage Mount 0.141" 3/32 0.141 Brass Electro-Tin YES
09-8048-1-044
09-8048-1-044
09-8048-1-044
0.597" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
10-218-4-044
10-218-4-044
10-218-4-044
0.402" - - Swage Mount 0.165" 1/8 0.094 Brass Bright Tin YES
10-462-11-04
10-462-11-04
10-462-11-04
0.193" - - Swage Mount 0.037" 1/64 0.052 Brass Electro-Tin YES
10-315-1-044
10-315-1-044
10-315-1-044
0.403" - - Swage Mount 0.075" 1/32 0.082 Brass Bright Tin YES
