Commercial
Non-Insulated
Terminals

Filter
10-501-4-095
10-501-4-095
10-501-4-095
0.331" - Turret/Turret Swage Mount 0.145" 1/8 0.076 Brass Hot Solder Dip NO
10-544-2-095
10-544-2-095
10-544-2-095
0.335" - Turret/Turret Swage Mount 0.094" 1/16 0.094 Brass Hot Solder Dip NO
10-504-1-095
10-504-1-095
10-504-1-095
0.469" - Double Turret/Double Turret Swage Mount 0.062" 1/32 0.094 Brass Hot Solder Dip NO
09-8832-1-095
09-8832-1-095
09-8832-1-095
0.327" 0.025 TURRET/PIN Swage Mount 0.051" 1/32 0.062 Brass Hot Solder Dip NO
10-226-2-095
10-226-2-095
10-226-2-095
0.465" - - Swage Mount 0.105" 1/16 0.206 Brass Hot Solder Dip NO
09-8598-3A-095
09-8598-3A-095
09-8598-3A-095
0.182" - - Swage Mount 0.122" 3/32 0.035 Brass Hot Solder Dip NO
09-0150-4-095
09-0150-4-095
09-0150-4-095
0.217" - - Swage Mount 0.147" 1/8 0.037 Brass Hot Solder Dip NO
10-512-2-095
10-512-2-095
10-512-2-095
0.476" - Double Turret/Double Turret Swage Mount 0.105" 1/16 0.129 Brass Hot Solder Dip NO
09-0353-2-095
09-0353-2-095
09-0353-2-095
0.375" - - Swage Mount 0.085" 1/16 0.067 Brass Hot Solder Dip NO
10-509-4-095
10-509-4-095
10-509-4-095
0.813" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.204 Brass Hot Solder Dip NO
10-505-3-095
10-505-3-095
10-505-3-095
0.448" - TURRET/DOUBLE TURRET Swage Mount 0.125" 3/32 0.094 Brass Hot Solder Dip NO
10-505-2-095
10-505-2-095
10-505-2-095
0.417" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.094 Brass Hot Solder Dip NO
10-446-1-095
10-446-1-095
10-446-1-095
0.445" - SLOTTED/DOUBLE TURRET Swage Mount 0.062" 1/32 0.096 Brass Hot Solder Dip NO
10-559-2-095
10-559-2-095
10-559-2-095
0.379" - TURRET/DOUBLE TURRET Swage Mount 0.084" 1/16 0.076 Brass Hot Solder Dip NO
10-914-2-095
10-914-2-095
10-914-2-095
0.282" - - Swage Mount 0.094" 1/16 0.0635 Brass Hot Solder Dip NO
10-556-3-03
10-556-3-03
10-556-3-03
0.416" - Turret/Turret Swage Mount 0.135" 3/32 0.116 Brass Gold YES
10-560-3-03
10-560-3-03
10-560-3-03
0.682" - TURRET/DOUBLE TURRET Swage Mount 0.135" 3/32 0.116 Brass Gold YES
10-434-2-03
10-434-2-03
10-434-2-03
0.373" - - Swage Mount 0.105" 1/16 0.189 Brass Gold YES
10-433-4-03
10-433-4-03
10-433-4-03
0.860" - - Swage Mount 0.172" 1/8 0.182 Brass Gold YES
10-714-2-03
10-714-2-03
10-714-2-03
0.667" - DOUBLE TURRET/THREAD Swage Mount 0.105" 1/16 0.204 Brass Gold YES
