Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
09-0265-1-035	0.221"	-	-	Swage Mount	0.065"	1/32	0.067	Brass	Gold	YES
09-8170-2-035	0.415"	0.025	-	Swage Mount	0.078"	1/16	0.035	Brass	Gold	YES
09-0166-1-035	0.201"	-	-	Swage Mount	0.045"	1/32	0.067	Brass	Gold	YES
09-8182-1-035	0.426"	0.020	-	Swage Mount	0.051"	1/32	0.035	Brass	Gold	YES
10-519-8-035	1.217"	-	Double Turret/Double Turret	Swage Mount	0.281"	1/4	0.266	Brass	Gold	YES
09-0164-3-035	0.371"	-	-	Swage Mount	0.121"	3/32	0.125	Brass	Gold	YES
10-804-1-035	0.500"	0.041	DOUBLE TURRET/PIN	Swage Mount	0.062"	1/32	0.125	Brass	Gold	YES
09-8047-2-035	0.655"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Gold	YES
10-312-6-035	0.558"	-	-	Swage Mount	0.230"	3/16	0.082	Brass	Gold	YES
10-266-4-035	0.303"	-	-	Swage Mount	0.147"	1/8	0.206	Brass	Gold	YES
10-421-3-035	0.604"	-	-	Swage Mount	0.135"	3/32	0.116	Brass	Gold	YES
10-137-3-035	0.300"	-	-	Swage Mount	0.141"	3/32	0.094	Brass	Gold	YES
09-8260-2-035	0.234"	-	-	Press Fit/Solder	0.078"	1/16	0.104	Brass	Gold	YES
10-901-4-035	0.312"	0.060	-	Swage Mount	0.156"	1/8	0.064	Brass	Gold	YES
09-8193-2A-035	0.377"	0.040	-	Swage Mount	0.097"	1/16	0.043	Brass	Gold	YES
09-0314-2-035	0.253"	-	-	Swage Mount	0.097"	1/16	0.047	Brass	Gold	YES
09-8193-2-035	0.392"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Gold	YES
10-990-1-035	0.571"	0.040	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8653-11-035	0.200"	-	-	Swage Mount	0.029"	1/64	0.037	Brass	Gold	YES
10-309-3-035	0.452"	-	-	Swage Mount	0.135"	3/32	0.116	Brass	Gold	YES
