Commercial
Non-Insulated
Terminals

Filter
09-8060-2-05
09-8060-2-05
09-8060-2-05
0.882" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
10-805-6-05
10-805-6-05
10-805-6-05
0.524" - - Swage Mount 0.234" 3/16 0.094 Brass Electro Solder NO
10-412-1-05
10-412-1-05
10-412-1-05
0.314" - - Swage Mount 0.075" 1/32 0.094 Brass Electro Solder NO
10-924-1-05
10-924-1-05
10-924-1-05
0.275" 0.025 - - - - - Brass Electro Solder NO
10-320-1-05
10-320-1-05
10-320-1-05
0.265" - - Swage Mount 0.075" 1/32 0.094 Brass Electro Solder NO
10-119-1-05
10-119-1-05
10-119-1-05
0.303" - - Swage Mount 0.075" 1/32 0.082 Brass Electro Solder NO
10-307-4-05
10-307-4-05
10-307-4-05
0.431" - - Swage Mount 0.165" 1/8 0.096 Brass Electro Solder NO
10-225-1-05
10-225-1-05
10-225-1-05
0.209" - - Swage Mount 0.053" 1/32 0.067 Brass Electro Solder NO
10-928-1-05
10-928-1-05
10-928-1-05
0.531" - TURRET/PIN Press Fit/Solder 0.375" 9/64 TO 5/16 0.096 Brass Electro Solder NO
09-0087-2-05
09-0087-2-05
09-0087-2-05
0.382" - SLOTTED/TURRET Solder 0.094" 1/16 0.096 Brass Electro Solder NO
10-231-2-05
10-231-2-05
10-231-2-05
0.260" - - Swage Mount 0.105" 1/16 0.116 Brass Electro Solder NO
10-445-3-05
10-445-3-05
10-445-3-05
0.413" - SLOTTED/TURRET Swage Mount 0.125" 3/32 0.096 Brass Electro Solder NO
10-543-4-05
10-543-4-05
10-543-4-05
0.601" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.094 Brass Electro Solder NO
10-559-4-05
10-559-4-05
10-559-4-05
0.442" - TURRET/DOUBLE TURRET Swage Mount 0.147" 1/8 0.076 Brass Electro Solder NO
10-490-2-05
10-490-2-05
10-490-2-05
0.511" - TURRET/SLOTTED Swage Mount 0.105" 1/16 0.120 Brass Electro Solder NO
09-8764-1-05
09-8764-1-05
09-8764-1-05
0.370" 0.040 - - - - - Brass Electro Solder NO
10-504-4-05
10-504-4-05
10-504-4-05
0.563" - Double Turret/Double Turret Swage Mount 0.156" 1/8 0.094 Brass Electro Solder NO
10-501-1A-05
10-501-1A-05
10-501-1A-05
0.254" - Turret/Turret Swage Mount 0.068" 1/32 0.076 Brass Electro Solder NO
10-512-8-01
10-512-8-01
10-512-8-01
0.661" - Double Turret/Double Turret Swage Mount 0.290" 1/4 0.129 Brass Silver YES
10-501-1-05
10-501-1-05
10-501-1-05
0.237" - Turret/Turret Swage Mount 0.051" 1/32 0.076 Brass Electro Solder NO
