Commercial
Non-Insulated
Terminals

Filter
09-0175-4-05
09-0175-4-05
09-0175-4-05
0.305" - - Swage Mount 0.150" 1/8 0.063 Brass Electro Solder NO
09-0303-3-03
09-0303-3-03
09-0303-3-03
0.271" - - Swage Mount 0.115" 3/32 0.063 Brass Gold YES
09-0303-3-088
09-0303-3-088
09-0303-3-088
0.271" - - Swage Mount 0.115" 3/32 0.063 Brass Bright Tin-Lead NO
09-8251-4-088
09-8251-4-088
09-8251-4-088
0.249" - - Swage Mount 0.145" 1/8 0.076 Brass Bright Tin-Lead NO
09-8251-2-03
09-8251-2-03
09-8251-2-03
0.202" - - Swage Mount 0.098" 1/16 0.076 Brass Gold YES
09-0234-3-03
09-0234-3-03
09-0234-3-03
0.425" - - Swage Mount 0.115" 3/32 0.067 Brass Gold YES
09-0303-3-01
09-0303-3-01
09-0303-3-01
0.271" - - Swage Mount 0.115" 3/32 0.063 Brass Silver YES
09-0303-3-04
09-0303-3-04
09-0303-3-04
0.271" - - Swage Mount 0.115" 3/32 0.063 Brass Electro-Tin YES
10-837-1-044
10-837-1-044
10-837-1-044
0.407" 0.050 Pin/Pin Swage Mount 0.063" 1/32 0.111 Brass Bright Tin YES
10-831-1-01
10-831-1-01
10-831-1-01
0.251" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Silver YES
10-831-1-03
10-831-1-03
10-831-1-03
0.251" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Gold YES
10-203-1-01
10-203-1-01
10-203-1-01
0.359" - - Swage Mount 0.078" 1/32 0.094 Brass Silver YES
10-838-1-044
10-838-1-044
10-838-1-044
0.594" 0.050 Pin/Pin Swage Mount 0.063" 1/32 0.111 Brass Bright Tin YES
10-832-1-03
10-832-1-03
10-832-1-03
0.313" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Gold YES
10-203-1-044
10-203-1-044
10-203-1-044
0.359" - - Swage Mount 0.078" 1/32 0.094 Brass Bright Tin YES
10-102-1-03
10-102-1-03
10-102-1-03
0.265" - - Swage Mount 0.078" 1/32 0.082 Brass Gold YES
10-838-1-01
10-838-1-01
10-838-1-01
0.594" 0.050 Pin/Pin Swage Mount 0.063" 1/32 0.111 Brass Silver YES
10-834-1-035
10-834-1-035
10-834-1-035
0.438" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Gold YES
10-102-1-095
10-102-1-095
10-102-1-095
0.265" - - Swage Mount 0.078" 1/32 0.082 Brass Hot Solder Dip NO
10-833-1-03
10-833-1-03
10-833-1-03
0.376" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Gold YES
