Commercial
Non-Insulated
Terminals

Filter
10-502-8-05
10-502-8-05
10-502-8-05
0.538" - TURRET/DOUBLE TURRET Swage Mount 0.270" 1/4 0.076 Brass Electro Solder NO
10-104-11-05
10-104-11-05
10-104-11-05
0.129" - - Swage Mount 0.035" 1/64 0.052 Brass Electro Solder NO
10-135-2-095
10-135-2-095
10-135-2-095
0.468" - - Swage Mount 0.109" 1/16 0.116 Brass Hot Solder Dip NO
09-7155-2-01
09-7155-2-01
09-7155-2-01
0.326" 0.058 - RIVET MOUNT 0.095" 1/16 0.060 Brass Silver YES
10-112-3-04
10-112-3-04
10-112-3-04
0.316" - - Swage Mount 0.135" 3/32 0.082 Brass Electro-Tin YES
10-134-1-095
10-134-1-095
10-134-1-095
0.219" - - Swage Mount 0.062" 1/32 0.081 Brass Hot Solder Dip NO
09-8301-1-04
09-8301-1-04
09-8301-1-04
0.234" 0.017 - Solder 0.061" 1/64 TO 1/32 0.0225 Brass Electro-Tin YES
10-807-3-044
10-807-3-044
10-807-3-044
0.484" - - Swage Mount 0.141" 3/32 0.094 Brass Bright Tin YES
10-490-5-05
10-490-5-05
10-490-5-05
0.602" - TURRET/SLOTTED Swage Mount 0.196" 5/32 0.120 Brass Electro Solder NO
09-8012-2-01
09-8012-2-01
09-8012-2-01
0.662" 0.020 - Swage Mount 0.082" 1/16 0.043 Brass Silver YES
10-501-4A-044
10-501-4A-044
10-501-4A-044
0.356" - Turret/Turret Swage Mount 0.170" 1/8 0.076 Brass Bright Tin YES
14-347-5-05
14-347-5-05
14-347-5-05
0.655" - - Swage Mount 0.195" 5/32 0.116 LEADED Red Brass Electro Solder NO
10-911-2-03
10-911-2-03
10-911-2-03
0.200" 0.046 - Swage Mount 0.090" 1/16 0.052 Brass Gold YES
10-858-4-088
10-858-4-088
10-858-4-088
0.625" 0.040 Pin/Pin Swage Mount 0.156" 1/8 0.094 Brass Bright Tin-Lead NO
10-858-4-035
10-858-4-035
10-858-4-035
0.625" 0.040 Pin/Pin Swage Mount 0.156" 1/8 0.094 Brass Gold YES
10-458-4-035
10-458-4-035
10-458-4-035
0.344" - - Swage Mount 0.156" 1/8 0.076 Brass Gold YES
10-920-1-01
10-920-1-01
10-920-1-01
0.171" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Silver YES
10-974-1-088
10-974-1-088
10-974-1-088
1.071" 0.040 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin-Lead NO
10-413-4-04
10-413-4-04
10-413-4-04
0.301" - - Swage Mount 0.145" 1/8 0.052 Brass Electro-Tin YES
10-413-3-01
10-413-3-01
10-413-3-01
0.269" - - Swage Mount 0.113" 3/32 0.052 Brass Silver YES
