Commercial
Non-Insulated
Terminals

Filter
09-8136-4-05
09-8136-4-05
09-8136-4-05
0.510" 0.040 TURRET/PIN Swage Mount 0.156" 1/8 0.125 Brass Electro Solder NO
09-0090-2-05
09-0090-2-05
09-0090-2-05
0.457" - Turret/Turret Swage Mount 0.094" 1/16 0.125 Brass Electro Solder NO
09-8136-1-05
09-8136-1-05
09-8136-1-05
0.416" 0.040 TURRET/PIN Swage Mount 0.062" 1/32 0.125 Brass Electro Solder NO
10-543-6-05
10-543-6-05
10-543-6-05
0.664" - Double Turret/Double Turret Swage Mount 0.219" 3/16 0.094 Brass Electro Solder NO
10-845-5-04
10-845-5-04
10-845-5-04
0.523" - - Swage Mount 0.195" 5/32 0.116 Brass Electro-Tin YES
10-826-1-044
10-826-1-044
10-826-1-044
0.403" - - Swage Mount 0.075" 1/32 0.081 Brass Bright Tin YES
10-824-6-01
10-824-6-01
10-824-6-01
0.759" 0.053 (TAPER) TURRET/TAPER PIN Swage Mount 0.219" 3/16 0.147 Brass Silver YES
10-821-2-04
10-821-2-04
10-821-2-04
0.438" 0.040 Pin/Pin Swage Mount 0.105" 1/16 0.094 Brass Electro-Tin YES
10-461-11-03
10-461-11-03
10-461-11-03
0.349" - - Swage Mount 0.037" 1/64 0.043 Brass Gold YES
10-443-3-04
10-443-3-04
10-443-3-04
0.380" - SLOTTED/TURRET Swage Mount 0.125" 3/32 0.125 Brass Electro-Tin YES
10-209-3-044
10-209-3-044
10-209-3-044
0.360" - - Swage Mount 0.141" 3/32 0.094 Brass Bright Tin YES
10-420-6-03
10-420-6-03
10-420-6-03
0.609" - - Swage Mount 0.234" 3/16 0.154 Brass Gold YES
09-0034-1-044
09-0034-1-044
09-0034-1-044
0.172" - - Swage Mount 0.066" 1/32 0.067 Brass Bright Tin YES
10-455-4-035
10-455-4-035
10-455-4-035
0.406" - - Swage Mount 0.156" 1/8 0.076 Brass Gold YES
10-530-6-05
10-530-6-05
10-530-6-05
0.694" - TURRET/DOUBLE TURRET Swage Mount 0.230" 3/16 0.159 Brass Electro Solder NO
10-525-4-088
10-525-4-088
10-525-4-088
0.583" - Double Turret/Double Turret Swage Mount 0.147" 1/8 0.094 Brass Bright Tin-Lead NO
09-8180-3-01
09-8180-3-01
09-8180-3-01
0.469" 0.020 - Swage Mount 0.119" 3/32 0.039 Brass Silver YES
10-457-6-01
10-457-6-01
10-457-6-01
0.375" - - Swage Mount 0.219" 3/16 0.076 Brass Silver YES
10-510-2-088
10-510-2-088
10-510-2-088
0.472" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.116 Brass Bright Tin-Lead NO
09-0150-1-01
09-0150-1-01
09-0150-1-01
0.123" - - Swage Mount 0.053" 1/32 0.037 Brass Silver YES
