Commercial
Non-Insulated
Terminals

Filter
10-114-11-05
10-114-11-05
10-114-11-05
0.131" - - Swage Mount 0.037" 1/64 0.043 Brass Electro Solder NO
10-215-3-088
10-215-3-088
10-215-3-088
0.269" - - Swage Mount 0.115" 3/32 0.063 Brass Bright Tin-Lead NO
10-408-6-088
10-408-6-088
10-408-6-088
0.542" - - Swage Mount 0.230" 3/16 0.116 Brass Bright Tin-Lead NO
10-532-5-088
10-532-5-088
10-532-5-088
0.663" - Double Turret/Double Turret Swage Mount 0.195" 5/32 0.159 Brass Bright Tin-Lead NO
10-204-2-088
10-204-2-088
10-204-2-088
0.468" - - Swage Mount 0.109" 1/16 0.116 Brass Bright Tin-Lead NO
09-0190-3-088
09-0190-3-088
09-0190-3-088
0.261" 0.040 - Swage Mount 0.125" 3/32 0.067 Brass Bright Tin-Lead NO
09-8689-1-088
09-8689-1-088
09-8689-1-088
0.174" 0.020 - Swage Mount 0.064" 1/32 0.043 Brass Bright Tin-Lead NO
09-0053-2-088
09-0053-2-088
09-0053-2-088
0.269" - - Press Fit/Solder 0.078" 1/16 0.073 Brass Bright Tin-Lead NO
10-607-2-088
10-607-2-088
10-607-2-088
0.526" - - Swage Mount 0.105" 1/16 0.116 Brass Bright Tin-Lead NO
09-8006-1-088
09-8006-1-088
09-8006-1-088
0.626" 0.020 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin-Lead NO
10-508-3-088
10-508-3-088
10-508-3-088
0.569" - TURRET/DOUBLE TURRET Swage Mount 0.125" 3/32 0.206 Brass Bright Tin-Lead NO
10-802-2-088
10-802-2-088
10-802-2-088
0.302" 0.032 TURRET/PIN Swage Mount 0.084" 1/16 0.067 Brass Bright Tin-Lead NO
10-938-1-088
10-938-1-088
10-938-1-088
0.385" 0.038 - Swage Mount 0.060" 1/32 0.042 Brass Bright Tin-Lead NO
10-522-3-088
10-522-3-088
10-522-3-088
0.604" - Turret/Turret Swage Mount 0.135" 3/32 0.206 Brass Bright Tin-Lead NO
10-508-2A-088
10-508-2A-088
10-508-2A-088
0.549" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.206 Brass Bright Tin-Lead NO
09-0008-1-088
09-0008-1-088
09-0008-1-088
0.900" 0.030 - Solder 0.188" 3/32 0.043 Brass Bright Tin-Lead NO
10-801-2-088
10-801-2-088
10-801-2-088
0.410" 0.040 TURRET/PIN Swage Mount 0.082" 1/16 0.076 Brass Bright Tin-Lead NO
09-8131-1-088
09-8131-1-088
09-8131-1-088
0.240" 0.032 TURRET/PIN Swage Mount 0.051" 1/32 0.067 Brass Bright Tin-Lead NO
09-0352-3-088
09-0352-3-088
09-0352-3-088
0.225" - - Press Fit/Solder 0.100" 3/32 0.047 Brass Bright Tin-Lead NO
10-810-1-088
10-810-1-088
10-810-1-088
0.390" - - Swage Mount 0.078" 1/32 0.1495 Brass Bright Tin-Lead NO
