Commercial
Non-Insulated
Terminals

Filter
10-304-2-095
10-304-2-095
10-304-2-095
0.421" - - Swage Mount 0.109" 1/16 0.1405 Brass Hot Solder Dip NO
10-424-4-03
10-424-4-03
10-424-4-03
0.602" - - Swage Mount 0.165" 1/8 0.141 Brass Gold YES
10-104-2-088
10-104-2-088
10-104-2-088
0.176" - - Swage Mount 0.082" 1/16 0.052 Brass Bright Tin-Lead NO
10-104-2-05
10-104-2-05
10-104-2-05
0.176" - - Swage Mount 0.082" 1/16 0.052 Brass Electro Solder NO
10-105-1-095
10-105-1-095
10-105-1-095
0.162" - - Swage Mount 0.053" 1/32 0.076 Brass Hot Solder Dip NO
10-105-11-03
10-105-11-03
10-105-11-03
0.146" - - Swage Mount 0.037" 1/64 0.076 Brass Gold YES
10-209-3-01
10-209-3-01
10-209-3-01
0.360" - - Swage Mount 0.141" 3/32 0.094 Brass Silver YES
10-106-1-044
10-106-1-044
10-106-1-044
0.256" - - Swage Mount 0.075" 1/32 0.094 Brass Bright Tin YES
10-106-1-03
10-106-1-03
10-106-1-03
0.256" - - Swage Mount 0.075" 1/32 0.094 Brass Gold YES
10-106-4-01
10-106-4-01
10-106-4-01
0.346" - - Swage Mount 0.165" 1/8 0.094 Brass Silver YES
10-135-2-044
10-135-2-044
10-135-2-044
0.468" - - Swage Mount 0.109" 1/16 0.116 Brass Bright Tin YES
10-135-2-04
10-135-2-04
10-135-2-04
0.468" - - Swage Mount 0.109" 1/16 0.116 Brass Electro-Tin YES
10-135-3-044
10-135-3-044
10-135-3-044
0.499" - - Swage Mount 0.140" 3/32 0.116 Brass Bright Tin YES
10-135-3-04
10-135-3-04
10-135-3-04
0.499" - - Swage Mount 0.140" 3/32 0.116 Brass Electro-Tin YES
09-8181-1-03
09-8181-1-03
09-8181-1-03
0.276" 0.020 - Swage Mount 0.051" 1/32 0.035 Brass Gold YES
10-201-3-05
10-201-3-05
10-201-3-05
0.299" - - Swage Mount 0.113" 3/32 0.076 Brass Electro Solder NO
10-201-3-044
10-201-3-044
10-201-3-044
0.299" - - Swage Mount 0.113" 3/32 0.076 Brass Bright Tin YES
10-201-3-088
10-201-3-088
10-201-3-088
0.299" - - Swage Mount 0.113" 3/32 0.076 Brass Bright Tin-Lead NO
10-515-5-04
10-515-5-04
10-515-5-04
0.961" 0.094 TURRET/PIN Swage Mount 0.195" 5/32 0.185 Brass Electro-Tin YES
10-515-4-035
10-515-4-035
10-515-4-035
0.931" 0.094 TURRET/PIN Swage Mount 0.165" 1/8 0.185 Brass Gold YES
