Commercial
Non-Insulated
Terminals

Filter
10-307-4-044
10-307-4-044
10-307-4-044
0.431" - - Swage Mount 0.165" 1/8 0.096 Brass Bright Tin YES
09-8405-8-01
09-8405-8-01
09-8405-8-01
0.640" - - Swage Mount 0.297" 1/4 0.096 Brass Silver YES
10-445-4-095
10-445-4-095
10-445-4-095
0.444" - SLOTTED/TURRET Swage Mount 0.156" 1/8 0.096 Brass Hot Solder Dip NO
10-969-2-01
10-969-2-01
10-969-2-01
0.269" 0.050 - Swage Mount 0.082" 1/16 0.055 Brass Silver YES
10-846-5-044
10-846-5-044
10-846-5-044
0.523" - - Swage Mount 0.195" 5/32 0.116 Brass Bright Tin YES
09-0022-2-044
09-0022-2-044
09-0022-2-044
0.294" - - Swage Mount 0.094" 1/16 0.076 Brass Bright Tin YES
09-0312-1-03
09-0312-1-03
09-0312-1-03
0.170" - - Solder 0.123" 3/32 0.089 Brass Gold YES
10-117-2-088
10-117-2-088
10-117-2-088
0.178" - - Swage Mount 0.084" 1/16 0.067 Brass Bright Tin-Lead NO
10-508-6-044
10-508-6-044
10-508-6-044
0.663" - TURRET/DOUBLE TURRET Swage Mount 0.219" 3/16 0.206 Brass Bright Tin YES
10-503-3-03
10-503-3-03
10-503-3-03
0.463" - Double Turret/Double Turret Swage Mount 0.113" 3/32 0.076 Brass Gold YES
10-503-3-088
10-503-3-088
10-503-3-088
0.463" - Double Turret/Double Turret Swage Mount 0.113" 3/32 0.076 Brass Bright Tin-Lead NO
10-503-4-01
10-503-4-01
10-503-4-01
0.495" - Double Turret/Double Turret Swage Mount 0.145" 1/8 0.076 Brass Silver YES
10-501-1A-095
10-501-1A-095
10-501-1A-095
0.254" - Turret/Turret Swage Mount 0.068" 1/32 0.076 Brass Hot Solder Dip NO
10-501-2-01
10-501-2-01
10-501-2-01
0.268" - Turret/Turret Swage Mount 0.082" 1/16 0.076 Brass Silver YES
10-812-2-03
10-812-2-03
10-812-2-03
0.594" - Turret/Turret Swage Mount 0.094" 1/16 0.147 Brass Gold YES
09-8073-2-088
09-8073-2-088
09-8073-2-088
0.340" 0.050 - Swage Mount 0.082" 1/16 0.052 Brass Bright Tin-Lead NO
09-8083-2-044
09-8083-2-044
09-8083-2-044
0.482" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Bright Tin YES
09-8083-2-05
09-8083-2-05
09-8083-2-05
0.482" 0.0405 - Swage Mount 0.082" 1/16 0.043 Brass Electro Solder NO
09-8083-4-01
09-8083-4-01
09-8083-4-01
0.550" 0.0405 - Swage Mount 0.150" 1/8 0.043 Brass Silver YES
09-8083-4-035
09-8083-4-035
09-8083-4-035
0.550" 0.0405 - Swage Mount 0.150" 1/8 0.043 Brass Gold YES
