Commercial
Non-Insulated
Terminals

Filter
10-226-3-05
10-226-3-05
10-226-3-05
0.495" - - Swage Mount 0.135" 3/32 0.206 Brass Electro Solder NO
10-101-8-05
10-101-8-05
10-101-8-05
0.374" - - Swage Mount 0.270" 1/4 0.076 Brass Electro Solder NO
10-467-3-05
10-467-3-05
10-467-3-05
0.823" - - Swage Mount 0.135" 3/32 0.1875 Brass Electro Solder NO
10-432-5-05
10-432-5-05
10-432-5-05
0.632" - - Swage Mount 0.195" 5/32 0.161 Brass Electro Solder NO
09-0050-3-05
09-0050-3-05
09-0050-3-05
0.453" - - Swage Mount 0.141" 3/32 0.140 Brass Electro Solder NO
10-424-1-05
10-424-1-05
10-424-1-05
0.512" - - Swage Mount 0.075" 1/32 0.141 Brass Electro Solder NO
10-754-4-05
10-754-4-05
10-754-4-05
0.687" - TURRET/THREAD Swage Mount 0.172" 1/8 0.242 Brass Electro Solder NO
10-465-2-05
10-465-2-05
10-465-2-05
0.484" - - Swage Mount 0.109" 1/16 0.1405 Brass Electro Solder NO
10-420-3-05
10-420-3-05
10-420-3-05
0.516" - - Swage Mount 0.141" 3/32 0.154 Brass Electro Solder NO
10-810-4-05
10-810-4-05
10-810-4-05
0.484" - - Swage Mount 0.172" 1/8 0.1495 Brass Electro Solder NO
10-810-6-05
10-810-6-05
10-810-6-05
0.546" - - Swage Mount 0.234" 3/16 0.1495 Brass Electro Solder NO
10-905-4-088
10-905-4-088
10-905-4-088
0.344" - - Swage Mount 0.156" 1/8 0.0635 Brass Bright Tin-Lead NO
10-803-4-095
10-803-4-095
10-803-4-095
0.520" 0.040 TURRET/PIN Swage Mount 0.145" 1/8 0.076 Brass Hot Solder Dip NO
10-101-2-01
10-101-2-01
10-101-2-01
0.186" - - Swage Mount 0.082" 1/16 0.076 Brass Silver YES
10-109-2-01
10-109-2-01
10-109-2-01
0.253" - - Swage Mount 0.094" 1/16 0.094 Brass Silver YES
09-0266-1-05
09-0266-1-05
09-0266-1-05
0.215" - - Swage Mount 0.059" 1/32 0.052 Brass Electro Solder NO
10-333-2-04
10-333-2-04
10-333-2-04
0.250" - - Swage Mount 0.094" 1/16 0.063 Brass Electro-Tin YES
10-501-4A-01
10-501-4A-01
10-501-4A-01
0.356" - Turret/Turret Swage Mount 0.170" 1/8 0.076 Brass Silver YES
10-914-2-05
10-914-2-05
10-914-2-05
0.282" - - Swage Mount 0.094" 1/16 0.0635 Brass Electro Solder NO
10-444-2-03
10-444-2-03
10-444-2-03
0.209" - - Swage Mount 0.084" 1/16 0.043 Brass Gold YES
