Commercial
Non-Insulated
Terminals

Filter
10-407-4-088
10-407-4-088
10-407-4-088
0.672" - - Swage Mount 0.172" 1/8 0.1405 Brass Bright Tin-Lead NO
10-218-1-088
10-218-1-088
10-218-1-088
0.312" - - Swage Mount 0.075" 1/32 0.094 Brass Bright Tin-Lead NO
19-246-6-044
19-246-6-044
19-246-6-044
0.593" - - Swage Mount 0.234" 3/16 0.116 LEADED Red Brass Bright Tin YES
09-0033-3-095
09-0033-3-095
09-0033-3-095
0.625" - TURRET/DOUBLE TURRET Swage Mount 0.156" 1/8 0.206 Brass Hot Solder Dip NO
09-8810-2-04
09-8810-2-04
09-8810-2-04
0.300" 0.040 - Swage Mount 0.094" 1/16 0.067 Brass Electro-Tin YES
10-226-2-044
10-226-2-044
10-226-2-044
0.465" - - Swage Mount 0.105" 1/16 0.206 Brass Bright Tin YES
10-502-2-03
10-502-2-03
10-502-2-03
0.350" - TURRET/DOUBLE TURRET Swage Mount 0.082" 1/16 0.076 Brass Gold YES
10-316-2-04
10-316-2-04
10-316-2-04
0.569" - - Swage Mount 0.105" 1/16 0.116 Brass Electro-Tin YES
10-108-4-03
10-108-4-03
10-108-4-03
0.240" - - Swage Mount 0.147" 1/8 0.067 Brass Gold YES
10-501-8-03
10-501-8-03
10-501-8-03
0.456" - Turret/Turret Swage Mount 0.270" 1/4 0.076 Brass Gold YES
10-512-3-05
10-512-3-05
10-512-3-05
0.506" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.129 Brass Electro Solder NO
10-107-2-035
10-107-2-035
10-107-2-035
0.187" - - Swage Mount 0.094" 1/16 0.067 Brass Gold YES
10-905-2-035
10-905-2-035
10-905-2-035
0.282" - - Swage Mount 0.094" 1/16 0.0635 Brass Gold YES
10-803-3-035
10-803-3-035
10-803-3-035
0.488" 0.040 TURRET/PIN Swage Mount 0.113" 3/32 0.076 Brass Gold YES
10-816-5-01
10-816-5-01
10-816-5-01
0.395" - - Swage Mount 0.195" 5/32 0.1495 Brass Silver YES
10-413-2-088
10-413-2-088
10-413-2-088
0.238" - - Swage Mount 0.082" 1/16 0.052 Brass Bright Tin-Lead NO
10-414-1-03
10-414-1-03
10-414-1-03
0.207" - - Swage Mount 0.051" 1/32 0.052 Brass Gold YES
09-6001-1-04
09-6001-1-04
09-6001-1-04
0.785" 0.025 SQ. TURRET/SQUARE-WRAP PC PIN Press Fit/Solder 0.150" 1/16 TO 1/8 0.055 Brass Electro-Tin YES
10-454-2-03
10-454-2-03
10-454-2-03
0.339" - - Swage Mount 0.089" 1/16 0.067 Brass Gold YES
10-212-2-03
10-212-2-03
10-212-2-03
0.371" - - Swage Mount 0.105" 1/16 0.116 Brass Gold YES
