Commercial
Non-Insulated
Terminals

10-562-1-095
10-562-1-095
10-562-1-095
0.543" - Double Turret/Double Turret Swage Mount 0.075" 1/32 0.159 Brass Hot Solder Dip NO
10-562-1-088
10-562-1-088
10-562-1-088
0.543" - Double Turret/Double Turret Swage Mount 0.075" 1/32 0.159 Brass Bright Tin-Lead NO
10-530-6-035
10-530-6-035
10-530-6-035
0.694" - TURRET/DOUBLE TURRET Swage Mount 0.230" 3/16 0.159 Brass Gold YES
10-562-3-03
10-562-3-03
10-562-3-03
0.603" - Double Turret/Double Turret Swage Mount 0.135" 3/32 0.159 Brass Gold YES
10-562-4-095
10-562-4-095
10-562-4-095
0.633" - Double Turret/Double Turret Swage Mount 0.165" 1/8 0.159 Brass Hot Solder Dip NO
10-337-2-03
10-337-2-03
10-337-2-03
0.531" - - Swage Mount 0.109" 1/16 0.125 Brass Gold YES
10-238-3-05
10-238-3-05
10-238-3-05
0.562" - - Swage Mount 0.141" 3/32 0.116 Brass Electro Solder NO
09-7178-2-03
09-7178-2-03
09-7178-2-03
0.544" - - RIVET MOUNT 0.123" 1/16 0.116 Brass Gold YES
10-110-2-01
10-110-2-01
10-110-2-01
0.339" - - Swage Mount 0.105" 1/16 0.116 Brass Silver YES
10-247-4-044
10-247-4-044
10-247-4-044
0.531" - - Swage Mount 0.172" 1/8 0.116 Brass Bright Tin YES
10-541-2-03
10-541-2-03
10-541-2-03
0.574" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.116 Brass Gold YES
10-240-8-04
10-240-8-04
10-240-8-04
0.653" - - Swage Mount 0.293" 1/4 0.116 Brass Electro-Tin YES
10-240-8-044
10-240-8-044
10-240-8-044
0.653" - - Swage Mount 0.293" 1/4 0.116 Brass Bright Tin YES
10-240-8-01
10-240-8-01
10-240-8-01
0.653" - - Swage Mount 0.293" 1/4 0.116 Brass Silver YES
10-312-6-05
10-312-6-05
10-312-6-05
0.558" - - Swage Mount 0.230" 3/16 0.082 Brass Electro Solder NO
10-825-3-05
10-825-3-05
10-825-3-05
0.463" - - Swage Mount 0.135" 3/32 0.081 Brass Electro Solder NO
10-134-3-05
10-134-3-05
10-134-3-05
0.282" - - Swage Mount 0.125" 3/32 0.081 Brass Electro Solder NO
10-412-3-05
10-412-3-05
10-412-3-05
0.374" - - Swage Mount 0.135" 3/32 0.094 Brass Electro Solder NO
09-0268-2A-05
09-0268-2A-05
09-0268-2A-05
0.384" - - Swage Mount 0.094" 1/16 0.094 Brass Electro Solder NO
10-426-2-05
10-426-2-05
10-426-2-05
0.324" - - Swage Mount 0.105" 1/16 0.094 Brass Electro Solder NO
