Commercial
Insulated
Pin Terminals

Filter
1106-15-0519
1106-15-0519
1106-15-0519
1.190" - - Press Fit 5/32 0.158 Brass Electro Solder - - PTFE White NO
1107-15-0514
1107-15-0514
1107-15-0514
0.572" 0.040 Pin/Pin Press Fit 3/32 0.158 Brass Electro Solder - - PTFE Yellow NO
1107-15-0511
1107-15-0511
1107-15-0511
0.572" 0.040 Pin/Pin Press Fit 3/32 0.158 Brass Electro Solder - - PTFE Brown NO
1100-15-0517
1100-15-0517
1100-15-0517
0.260" 0.040 - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Violet NO
1110-14-0318
1110-14-0318
1110-14-0318
0.443" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Gold - - PTFE Gray NO
1102-15-0118
1102-15-0118
1102-15-0118
0.375" - - Press Fit 3/32 0.136 Brass Silver - - PTFE Gray NO
1102-15-0119
1102-15-0119
1102-15-0119
0.375" - - Press Fit 3/32 0.136 Brass Silver - - PTFE White YES
1156-15-0115
1156-15-0115
1156-15-0115
1.061" 0.050 DOUBLE TURRET/PIN Press Fit 7/32 0.158 Brass Silver - - PTFE Green YES
1100-15-0515
1100-15-0515
1100-15-0515
0.260" 0.040 - Press Fit 1/32 0.136 Brass Electro Solder - - PTFE Green NO
1112R-15-08818
1112R-15-08818
1112R-15-08818
0.351" - - Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Gray NO
1106-15-08819
1106-15-08819
1106-15-08819
1.190" - - Press Fit 5/32 0.158 Brass Bright Tin-Lead - - PTFE White NO
1127-15-0115
1127-15-0115
1127-15-0115
0.665" 0.070 - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Green YES
1102-15-08817
1102-15-08817
1102-15-08817
0.375" - - Press Fit 3/32 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1127-15-0119
1127-15-0119
1127-15-0119
0.665" 0.070 - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE White YES
1156-15-0519
1156-15-0519
1156-15-0519
1.061" 0.050 DOUBLE TURRET/PIN Press Fit 7/32 0.158 Brass Electro Solder - - PTFE White NO
1111-14S-0512
1111-14S-0512
1111-14S-0512
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Red NO
1111-14S-0414
1111-14S-0414
1111-14S-0414
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro-Tin - - PTFE Yellow NO
1111-14S-0518
1111-14S-0518
1111-14S-0518
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Gray NO
1111-14S-08814
1111-14S-08814
1111-14S-08814
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Yellow NO
1111-14S-04419
1111-14S-04419
1111-14S-04419
0.609" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin - - PTFE White YES

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
