Commercial
Insulated
Pin Terminals

Filter
1100-93-0114
1100-93-0114
1100-93-0114
0.315" 0.030 - Press Fit 1/16 0.086 Brass Silver - - PTFE Yellow NO
1114-30-0110
1114-30-0110
1114-30-0110
0.645" 0.080 - Press Fit 9/32 0.205 Brass Silver - - PTFE Black YES
1113-54-0311
1113-54-0311
1113-54-0311
0.327" 0.030 Pin/Pin Press Fit 1/16 0.070 Brass Gold - - PTFE Brown NO
1119-22-08812
1119-22-08812
1119-22-08812
1.500" 0.030 TURRET/PIN Press Fit 3/32 0.070 Brass Bright Tin-Lead - - PTFE Red NO
1121-27-0412
1121-27-0412
1121-27-0412
1.365" 0.050 Turret/Tip Press Fit 15/32 0.205 Brass Electro-Tin - - PTFE Red NO
1135-03-0510
1135-03-0510
1135-03-0510
0.635" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Electro Solder - - PTFE Black NO
1135-08-04411
1135-08-04411
1135-08-04411
0.425" 0.030 Pin/Slotted Press Fit 1/16 0.086 Brass Bright Tin - - PTFE Brown NO
09-2105-1-0118
09-2105-1-0118
09-2105-1-0118
0.510" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Silver - - PTFE Gray NO
1125-52-0517
1125-52-0517
1125-52-0517
0.912" - - 6-32 Nut Up to 3/16 0.144 Brass Electro Solder Electro-Tin Brass PTFE Violet NO
1102-34-04418
1102-34-04418
1102-34-04418
0.556" - - Press Fit 1/8 0.152 Brass Bright Tin - - PTFE Gray NO
1175-302-0314
1175-302-0314
1175-302-0314
0.491" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Gold - - PTFE Yellow NO
1105-01-0512
1105-01-0512
1105-01-0512
1.187" - Double Turret/Double Turret Press Fit Up to 5/16 0.205 Brass Electro Solder - - PTFE Red NO
1119-22-0517
1119-22-0517
1119-22-0517
1.500" 0.030 TURRET/PIN Press Fit 3/32 0.070 Brass Electro Solder - - PTFE Violet NO
1121R-07-0418
1121R-07-0418
1121R-07-0418
0.500" 0.040 Turret/Tip Press Fit 3/32 0.136 Brass Electro-Tin - - PTFE Gray NO
1135-03-04413
1135-03-04413
1135-03-04413
0.635" 0.030 Pin/Slotted Press Fit 1/32 0.070 Brass Bright Tin - - PTFE Orange NO
1110-85-08816
1110-85-08816
1110-85-08816
0.975" 0.035 Pin/Pin Press Fit 9/32 0.076 Brass Bright Tin-Lead - - PTFE Blue NO
1177-52-0115
1177-52-0115
1177-52-0115
0.515" 0.040 Pin/Pin PRESS LOCK 1/32 - 1/16 0.086 Brass Silver - - PTFE Green YES
1126-25-0519
1126-25-0519
1126-25-0519
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Electro Solder ZINC Brass PTFE White NO
1175-011-04410
1175-011-04410
1175-011-04410
0.609" 0.047 Pin/Pin PRESS LOCK 1/32 0.142 (+0.003/-0.001) Brass Bright Tin - - PTFE Black YES
1125-37-0310
1125-37-0310
1125-37-0310
0.975" - - 6-32 Nut Up to 1/4 0.144 Brass Gold Electro-Tin Brass PTFE Black YES
