Commercial
Insulated
Pin Terminals

Filter
1125-91-0119
1125-91-0119
1125-91-0119
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver Electro-Tin Brass PTFE White YES
1102-91-0518
1102-91-0518
1102-91-0518
0.276" - - Press Fit 3/32 0.086 Brass Electro Solder - - PTFE Gray NO
1102-91-0516
1102-91-0516
1102-91-0516
0.276" - - Press Fit 3/32 0.086 Brass Electro Solder - - PTFE Blue NO
1102-91-0515
1102-91-0515
1102-91-0515
0.276" - - Press Fit 3/32 0.086 Brass Electro Solder - - PTFE Green NO
1102-91-0513
1102-91-0513
1102-91-0513
0.276" - - Press Fit 3/32 0.086 Brass Electro Solder - - PTFE Orange NO
1102-91-0511
1102-91-0511
1102-91-0511
0.276" - - Press Fit 3/32 0.086 Brass Electro Solder - - PTFE Brown NO
1125-91-08812
1125-91-08812
1125-91-08812
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Red NO
1125-91-0418
1125-91-0418
1125-91-0418
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro-Tin Electro-Tin Brass PTFE Gray NO
1125-91-0413
1125-91-0413
1125-91-0413
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro-Tin Electro-Tin Brass PTFE Orange NO
1102-91-0313
1102-91-0313
1102-91-0313
0.276" - - Press Fit 3/32 0.086 Brass Gold - - PTFE Orange NO
1102-91-0314
1102-91-0314
1102-91-0314
0.276" - - Press Fit 3/32 0.086 Brass Gold - - PTFE Yellow NO
1102-91-0318
1102-91-0318
1102-91-0318
0.276" - - Press Fit 3/32 0.086 Brass Gold - - PTFE Gray NO
1125-91-08811
1125-91-08811
1125-91-08811
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Brown NO
1125-91-08814
1125-91-08814
1125-91-08814
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Yellow NO
1125-91-08817
1125-91-08817
1125-91-08817
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Violet NO
1125-91-08818
1125-91-08818
1125-91-08818
0.550" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead Electro-Tin Brass PTFE Gray NO
1127-91-0119
1127-91-0119
1127-91-0119
0.674" - - Swage Mount 3/32 0.082 Brass Silver ZINC Brass DIALLYL PHTHALATE White YES
1102-91-0417
1102-91-0417
1102-91-0417
0.276" - - Press Fit 3/32 0.086 Brass Electro-Tin - - PTFE Violet YES
1127-91-0418
1127-91-0418
1127-91-0418
0.674" - - Swage Mount 3/32 0.082 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1102-91-0418
1102-91-0418
1102-91-0418
0.276" - - Press Fit 3/32 0.086 Brass Electro-Tin - - PTFE Gray NO
