Commercial
Insulated
Pin Terminals

Filter
1154-51-04414
1154-51-04414
1154-51-04414
0.731" - DOUBLE TURRET/SLOTTED Press Fit Up to 3/16 0.205 Brass Bright Tin - - PTFE Yellow NO
1117-51-08814
1117-51-08814
1117-51-08814
0.590" 0.029 Pin/Pin 4-40 Nut 1/16 0.120 Brass Bright Tin-Lead Nickel Brass PTFE Yellow NO
1127-51-08812
1127-51-08812
1127-51-08812
0.844" - - Swage Mount 3/32 0.147 Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Red NO
1127-51-0412
1127-51-0412
1127-51-0412
0.844" - - Swage Mount 3/32 0.147 Brass Electro-Tin ZINC Brass DIALLYL PHTHALATE Red YES
1111-51-08811
1111-51-08811
1111-51-08811
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 1/4 0.205 Brass Bright Tin-Lead - - PTFE Brown NO
1113-51-04410
1113-51-04410
1113-51-04410
0.588" 0.030 Pin/Pin Press Fit 1/16 0.070 Brass Bright Tin - - PTFE Black YES
1154-51-08811
1154-51-08811
1154-51-08811
0.731" - DOUBLE TURRET/SLOTTED Press Fit Up to 3/16 0.205 Brass Bright Tin-Lead - - PTFE Brown NO
1110-51-08815
1110-51-08815
1110-51-08815
0.515" 0.040 Pin/Pin Press Fit 1/16 0.158 Brass Bright Tin-Lead - - PTFE Green NO
1127-51-04410
1127-51-04410
1127-51-04410
0.844" - - Swage Mount 3/32 0.147 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Black YES
1117-51-08813
1117-51-08813
1117-51-08813
0.590" 0.029 Pin/Pin 4-40 Nut 1/16 0.120 Brass Bright Tin-Lead Nickel Brass PTFE Orange NO
1111-51-08818
1111-51-08818
1111-51-08818
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 1/4 0.205 Brass Bright Tin-Lead - - PTFE Gray NO
1117-51-08812
1117-51-08812
1117-51-08812
0.590" 0.029 Pin/Pin 4-40 Nut 1/16 0.120 Brass Bright Tin-Lead Nickel Brass PTFE Red NO
1110-51-0417
1110-51-0417
1110-51-0417
0.515" 0.040 Pin/Pin Press Fit 1/16 0.158 Brass Electro-Tin - - PTFE Violet YES
1106R-51-0410
1106R-51-0410
1106R-51-0410
0.150" - - Press Fit 1/32 0.113 Brass Electro-Tin - - PTFE Black YES
1117-51-0312
1117-51-0312
1117-51-0312
0.590" 0.029 Pin/Pin 4-40 Nut 1/16 0.120 Brass Gold Nickel Brass PTFE Red NO
1117-51-04419
1117-51-04419
1117-51-04419
0.590" 0.029 Pin/Pin 4-40 Nut 1/16 0.120 Brass Bright Tin Nickel Brass PTFE White YES
09-2084-1-08812
09-2084-1-08812
09-2084-1-08812
1.074" 0.040 ± 0.010 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Red NO
09-2084-1-08814
09-2084-1-08814
09-2084-1-08814
1.074" 0.040 ± 0.010 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Yellow NO
09-2084-1-08818
09-2084-1-08818
09-2084-1-08818
1.074" 0.040 ± 0.010 Pin/Pin Press Fit 1/16 0.086 Brass Bright Tin-Lead - - PTFE Gray NO
09-2094-1-08814
09-2094-1-08814
09-2094-1-08814
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Bright Tin-Lead - - PTFE Yellow NO
