Commercial
Insulated
Pin Terminals

Filter
1127-37-04418
1127-37-04418
1127-37-04418
0.828" - - Swage Mount 3/16 0.147 Brass Bright Tin ZINC Brass DIALLYL PHTHALATE Gray YES
1127-37-0113
1127-37-0113
1127-37-0113
0.828" - - Swage Mount 3/16 0.147 Brass Silver ZINC Brass DIALLYL PHTHALATE Orange YES
1100-37-0413
1100-37-0413
1100-37-0413
0.460" 0.040 - Press Fit 1/16 0.136 Brass Electro-Tin - - PTFE Orange NO
1127-37-0112
1127-37-0112
1127-37-0112
0.828" - - Swage Mount 3/16 0.147 Brass Silver ZINC Brass DIALLYL PHTHALATE Red YES
1127-37-0317
1127-37-0317
1127-37-0317
0.828" - - Swage Mount 3/16 0.147 Brass Gold ZINC Brass DIALLYL PHTHALATE Violet YES
1126-37-0317
1126-37-0317
1126-37-0317
0.750" - - 6-32 Nut 1/8 0.144 Brass Gold ZINC Brass PTFE Violet YES
1111-37-08811
1111-37-08811
1111-37-08811
0.500" 0.053 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Brown NO
1127-93-0316
1127-93-0316
1127-93-0316
0.547" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Gold ZINC Brass DIALLYL PHTHALATE Blue YES
1125-93-08811
1125-93-08811
1125-93-08811
0.594" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Bright Tin-Lead ZINC Brass PTFE Brown NO
1127-93-0110
1127-93-0110
1127-93-0110
0.547" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Black YES
1127-93-0115
1127-93-0115
1127-93-0115
0.547" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Green YES
1127-93-0117
1127-93-0117
1127-93-0117
0.547" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Violet YES
1127-93-0118
1127-93-0118
1127-93-0118
0.547" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Silver ZINC Brass DIALLYL PHTHALATE Gray YES
1102R-93-0113
1102R-93-0113
1102R-93-0113
0.415" - - Press Fit 1/8 0.136 Brass Silver - - PTFE Orange NO
1102-93-08812
1102-93-08812
1102-93-08812
0.415" - - Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Red NO
1102-93-0116
1102-93-0116
1102-93-0116
0.415" - - Press Fit 1/8 0.136 Brass Silver - - PTFE Blue YES
1102R-93-0519
1102R-93-0519
1102R-93-0519
0.415" - - Press Fit 1/8 0.136 Brass Electro Solder - - PTFE White NO
1127-92-08810
1127-92-08810
1127-92-08810
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Bright Tin-Lead ZINC Brass DIALLYL PHTHALATE Black NO
1127-92-0519
1127-92-0519
1127-92-0519
0.390" - - 2-56 Screw - CLEARANCE FOR #2 Screw Brass Electro Solder ZINC Brass DIALLYL PHTHALATE White NO
1102R-92-0316
1102R-92-0316
1102R-92-0316
0.460" - - Press Fit 3/32 0.172 Brass Gold - - PTFE Blue YES
