Commercial
Insulated
Pin Terminals

Filter
1175-872-0515
1175-872-0515
1175-872-0515
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro Solder - - PTFE Green NO
1175-872-0511
1175-872-0511
1175-872-0511
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro Solder - - PTFE Brown NO
1175-872-0517
1175-872-0517
1175-872-0517
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro Solder - - PTFE Violet NO
1175-872-0518
1175-872-0518
1175-872-0518
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro Solder - - PTFE Gray NO
1175-872-0111
1175-872-0111
1175-872-0111
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Silver - - PTFE Brown NO
1175-872-0314
1175-872-0314
1175-872-0314
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Gold - - PTFE Yellow NO
1175-872-0412
1175-872-0412
1175-872-0412
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro-Tin - - PTFE Red NO
1175-872-0510
1175-872-0510
1175-872-0510
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro Solder - - PTFE Black NO
1175-872-0310
1175-872-0310
1175-872-0310
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Gold - - PTFE Black YES
1175-872-04411
1175-872-04411
1175-872-04411
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE Brown NO
1175-872-04419
1175-872-04419
1175-872-04419
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE White YES
1175-872-04417
1175-872-04417
1175-872-04417
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE Violet YES
1175-872-04414
1175-872-04414
1175-872-04414
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE Yellow NO
1175-872-0418
1175-872-0418
1175-872-0418
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro-Tin - - PTFE Gray NO
1175-872-0410
1175-872-0410
1175-872-0410
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Electro-Tin - - PTFE Black YES
1175-872-0319
1175-872-0319
1175-872-0319
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Gold - - PTFE White YES
1175-872-0311
1175-872-0311
1175-872-0311
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Gold - - PTFE Brown NO
1175-872-04415
1175-872-04415
1175-872-04415
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE Green YES
1175-872-04416
1175-872-04416
1175-872-04416
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Bright Tin - - PTFE Blue YES
1175-872-0317
1175-872-0317
1175-872-0317
0.591" 0.040 DOUBLE Turret/Tip PRESS LOCK 1/16 0.126 (+0.003/-0.001) Brass Gold - - PTFE Violet YES
