Commercial
Insulated
Pin Terminals

Filter
09-2095-1-0515
09-2095-1-0515
09-2095-1-0515
0.636" 0.060 ± 0.010 Pin/Pin Press Fit 1/8 0.136 Brass Electro Solder - - PTFE Green NO
09-2119-1-0512
09-2119-1-0512
09-2119-1-0512
1.200" 0.045 Pin/Pin Press Fit 5/32 0.158 Brass Electro Solder - - PTFE Red NO
09-2109-1-0419
09-2109-1-0419
09-2109-1-0419
1.180" 0.0405 - Press Fit 3/32 0.147 Brass Electro-Tin - - PTFE White YES
09-2099-1-0510
09-2099-1-0510
09-2099-1-0510
0.410" 0.030 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Black NO
09-2099-1-0511
09-2099-1-0511
09-2099-1-0511
0.410" 0.030 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Brown NO
09-2099-1-0513
09-2099-1-0513
09-2099-1-0513
0.410" 0.030 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Orange NO
09-2099-1-0517
09-2099-1-0517
09-2099-1-0517
0.410" 0.030 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE Violet NO
09-2099-1-0519
09-2099-1-0519
09-2099-1-0519
0.410" 0.030 Pin/Pin Press Fit 1/16 0.086 Brass Electro Solder - - PTFE White NO
09-2112-1-0119
09-2112-1-0119
09-2112-1-0119
0.838" - - 6-32 Nut 1/8 0.144 Brass Silver Nickel Brass PTFE White YES
09-2112-1-0118
09-2112-1-0118
09-2112-1-0118
0.838" - - 6-32 Nut 1/8 0.144 Brass Silver Nickel Brass PTFE Gray NO
09-2109-1-0517
09-2109-1-0517
09-2109-1-0517
1.180" 0.0405 - Press Fit 3/32 0.147 Brass Electro Solder - - PTFE Violet NO
09-2109-1-0514
09-2109-1-0514
09-2109-1-0514
1.180" 0.0405 - Press Fit 3/32 0.147 Brass Electro Solder - - PTFE Yellow NO
09-2109-1-0510
09-2109-1-0510
09-2109-1-0510
1.180" 0.0405 - Press Fit 3/32 0.147 Brass Electro Solder - - PTFE Black NO
09-2109-1-0511
09-2109-1-0511
09-2109-1-0511
1.180" 0.0405 - Press Fit 3/32 0.147 Brass Electro Solder - - PTFE Brown NO
09-2121-1-0115
09-2121-1-0115
09-2121-1-0115
0.275" - - Press Fit 5/64 0.136 Brass Silver - - PTFE Green YES
09-2094-1-0510
09-2094-1-0510
09-2094-1-0510
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Electro Solder - - PTFE Black NO
09-2094-1-0511
09-2094-1-0511
09-2094-1-0511
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Electro Solder - - PTFE Brown NO
09-2094-1-0512
09-2094-1-0512
09-2094-1-0512
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Electro Solder - - PTFE Red NO
09-2094-1-0515
09-2094-1-0515
09-2094-1-0515
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Electro Solder - - PTFE Green NO
09-2094-1-0517
09-2094-1-0517
09-2094-1-0517
0.593" 0.050 ± 0.010 Pin/Hook Press Fit 3/32 0.191 Brass Electro Solder - - PTFE Violet NO
