Commercial
Insulated
Pin Terminals

Filter
1140-03-04417
1140-03-04417
1140-03-04417
0.869" - Slotted/Slotted Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Violet YES
1129-03-08811
1129-03-08811
1129-03-08811
2.000" 0.030 TURRET/PIN Press Fit 1/8 0.172 Brass Bright Tin-Lead - - PTFE Brown NO
1153-01-08813
1153-01-08813
1153-01-08813
0.475" 0.040 Pin/Pin Press Fit 1/32 0.113 Brass Bright Tin-Lead - - PTFE Orange NO
1131-09-08815
1131-09-08815
1131-09-08815
0.415" 0.040 Pin/Tip Press Fit 1/16 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1175-462-08811
1175-462-08811
1175-462-08811
0.392" - - PRESS LOCK 1/16 0.142 (+0.003/-0.001) Brass Bright Tin-Lead - - PTFE Brown NO
1127-58-0514
1127-58-0514
1127-58-0514
0.641" - - 2-56 Nut 1/8 0.094 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Yellow NO
1125-80-04415
1125-80-04415
1125-80-04415
0.594" - - 6-32 Screw - CLEARANCE FOR #6 Screw Brass Bright Tin ZINC Brass PTFE Green YES
1156R-01-0419
1156R-01-0419
1156R-01-0419
0.460" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.086 Brass Electro-Tin - - PTFE White YES
09-2101-1-0315
09-2101-1-0315
09-2101-1-0315
0.572" - - PRESS LOCK 1/32 - 1/16 0.173 Brass Gold - - PTFE Green YES
1125-76-08812
1125-76-08812
1125-76-08812
0.666" - - Swage Mount 1/16 0.194 Brass Bright Tin-Lead ZINC Brass PTFE Red NO
1111-51-04412
1111-51-04412
1111-51-04412
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 1/4 0.205 Brass Bright Tin - - PTFE Red NO
1111-51-0511
1111-51-0511
1111-51-0511
0.828" 0.062 DOUBLE Turret/Tip Press Fit Up to 1/4 0.205 Brass Electro Solder - - PTFE Brown NO
1154-51-0410
1154-51-0410
1154-51-0410
0.731" - DOUBLE TURRET/SLOTTED Press Fit Up to 3/16 0.205 Brass Electro-Tin - - PTFE Black YES
1111-50-08815
1111-50-08815
1111-50-08815
0.531" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.136 Brass Bright Tin-Lead - - PTFE Green NO
1127-50-0512
1127-50-0512
1127-50-0512
0.813" - - Swage Mount 1/16 0.147 Brass Electro Solder ZINC Brass DIALLYL PHTHALATE Red NO
1175-493-04416
1175-493-04416
1175-493-04416
0.863" - Double Turret/Double Turret PRESS LOCK 3/32 0.188 (+0.003/-0.001) Brass Bright Tin - - PTFE Blue YES
1175-492-0412
1175-492-0412
1175-492-0412
0.831" - Double Turret/Double Turret PRESS LOCK 1/16 0.188 (+0.003/-0.001) Brass Electro-Tin - - PTFE Red NO
1175-492-0411
1175-492-0411
1175-492-0411
0.831" - Double Turret/Double Turret PRESS LOCK 1/16 0.188 (+0.003/-0.001) Brass Electro-Tin - - PTFE Brown NO
1175-491-0112
1175-491-0112
1175-491-0112
0.800" - Double Turret/Double Turret PRESS LOCK 1/32 0.188 (+0.003/-0.001) Brass Silver - - PTFE Red NO
1175-491-04417
1175-491-04417
1175-491-04417
0.800" - Double Turret/Double Turret PRESS LOCK 1/32 0.188 (+0.003/-0.001) Brass Bright Tin - - PTFE Violet YES
