Commercial
Insulated
Pin Terminals

Filter
1101-04-0112
1101-04-0112
1101-04-0112
0.415" - - Press Fit 1/8 0.136 Brass Silver - - PTFE Red NO
1157-04-0519
1157-04-0519
1157-04-0519
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE White NO
1157-04-0517
1157-04-0517
1157-04-0517
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Violet NO
1157-04-0514
1157-04-0514
1157-04-0514
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Yellow NO
1157-04-0511
1157-04-0511
1157-04-0511
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Brown NO
1157-04-0510
1157-04-0510
1157-04-0510
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Black NO
1108-04-0510
1108-04-0510
1108-04-0510
0.819" - Double Turret/Double Turret Press Fit Up to 3/16 0.158 Brass Electro Solder - - PTFE Black NO
1111-04-0519
1111-04-0519
1111-04-0519
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Electro Solder - - PTFE White NO
1111-04-0512
1111-04-0512
1111-04-0512
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Red NO
1111-04-0511
1111-04-0511
1111-04-0511
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Brown NO
1100-04-0517
1100-04-0517
1100-04-0517
0.250" 0.040 - Press Fit 3/64 0.086 Brass Electro Solder - - PTFE Violet NO
1114-04-0517
1114-04-0517
1114-04-0517
0.225" 0.040 - Press Fit 1/32 0.086 Brass Electro Solder - - PTFE Violet NO
1114-04-0516
1114-04-0516
1114-04-0516
0.225" 0.040 - Press Fit 1/32 0.086 Brass Electro Solder - - PTFE Blue NO
1114-04-0511
1114-04-0511
1114-04-0511
0.225" 0.040 - Press Fit 1/32 0.086 Brass Electro Solder - - PTFE Brown NO
1111-04-0510
1111-04-0510
1111-04-0510
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Black NO
1111-04-0514
1111-04-0514
1111-04-0514
0.500" 0.040 DOUBLE Turret/Tip Press Fit 1/32 0.113 Brass Electro Solder - - PTFE Yellow NO
1101-04-0113
1101-04-0113
1101-04-0113
0.415" - - Press Fit 1/8 0.136 Brass Silver - - PTFE Orange NO
1115-04-0512
1115-04-0512
1115-04-0512
0.710" 0.085 - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Red NO
1115-04-0517
1115-04-0517
1115-04-0517
0.710" 0.085 - Press Fit 1/8 0.158 Brass Electro Solder - - PTFE Violet NO
1157-04-0118
1157-04-0118
1157-04-0118
0.740" 0.050 TURRET/PIN Press Fit Up to 3/16 0.158 Brass Silver - - PTFE Gray NO
