Commercial
Non-Insulated
Terminals

Filter
10-502-1-035
10-502-1-035
10-502-1-035
0.319" - TURRET/DOUBLE TURRET Swage Mount 0.051" 1/32 0.076 Brass Gold YES
10-502-1-05
10-502-1-05
10-502-1-05
0.319" - TURRET/DOUBLE TURRET Swage Mount 0.051" 1/32 0.076 Brass Electro Solder NO
10-512-1-095
10-512-1-095
10-512-1-095
0.446" - Double Turret/Double Turret Swage Mount 0.075" 1/32 0.129 Brass Hot Solder Dip NO
10-206-4-05
10-206-4-05
10-206-4-05
0.338" - - Swage Mount 0.147" 1/8 0.076 Brass Electro Solder NO
10-505-1-044
10-505-1-044
10-505-1-044
0.385" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.094 Brass Bright Tin YES
10-505-1-088
10-505-1-088
10-505-1-088
0.385" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.094 Brass Bright Tin-Lead NO
10-505-1-095
10-505-1-095
10-505-1-095
0.385" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.094 Brass Hot Solder Dip NO
10-506-3-04
10-506-3-04
10-506-3-04
0.406" - Turret/Turret Swage Mount 0.125" 3/32 0.120 Brass Electro-Tin YES
10-506-6-03
10-506-6-03
10-506-6-03
0.500" - Turret/Turret Swage Mount 0.219" 3/16 0.120 Brass Gold YES
10-506-6-088
10-506-6-088
10-506-6-088
0.500" - Turret/Turret Swage Mount 0.219" 3/16 0.120 Brass Bright Tin-Lead NO
10-430-2-01
10-430-2-01
10-430-2-01
0.240" - - Swage Mount 0.084" 1/16 0.064 Brass Silver YES
10-508-1-03
10-508-1-03
10-508-1-03
0.506" - TURRET/DOUBLE TURRET Swage Mount 0.062" 1/32 0.206 Brass Gold YES
09-0078-1-03
09-0078-1-03
09-0078-1-03
0.209" - - Swage Mount 0.053" 1/32 0.076 Brass Gold YES
10-101-1-03
10-101-1-03
10-101-1-03
0.155" - - Swage Mount 0.051" 1/32 0.076 Brass Gold YES
10-508-2-035
10-508-2-035
10-508-2-035
0.538" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Gold YES
10-508-2-05
10-508-2-05
10-508-2-05
0.538" - TURRET/DOUBLE TURRET Swage Mount 0.094" 1/16 0.206 Brass Electro Solder NO
10-508-2A-04
10-508-2A-04
10-508-2A-04
0.549" - TURRET/DOUBLE TURRET Swage Mount 0.105" 1/16 0.206 Brass Electro-Tin YES
14-345-2-044
14-345-2-044
14-345-2-044
0.436" - - Swage Mount 0.109" 1/16 0.116 LEADED Red Brass Bright Tin YES
14-345-5-05
14-345-5-05
14-345-5-05
0.522" - - Swage Mount 0.195" 5/32 0.116 LEADED Red Brass Electro Solder NO
14-346-2-03
14-346-2-03
14-346-2-03
0.297" - - Swage Mount 0.109" 1/16 0.082 LEADED Red Brass Gold YES
