Commercial
Non-Insulated
Terminals

Filter
09-7016-4-05
09-7016-4-05
09-7016-4-05
0.310" - - Swage Mount 0.150" 1/8 0.055 Brass Electro Solder NO
09-7017-3-088
09-7017-3-088
09-7017-3-088
0.285" - - Swage Mount 0.125" 3/32 0.055 LEADED Red Brass Bright Tin-Lead NO
09-7017-2-088
09-7017-2-088
09-7017-2-088
0.255" - - Swage Mount 0.095" 1/16 0.055 LEADED Red Brass Bright Tin-Lead NO
09-7012-4-04
09-7012-4-04
09-7012-4-04
0.310" - - Swage Mount 0.150" 1/8 0.067 Brass Electro-Tin YES
09-7013-3-095
09-7013-3-095
09-7013-3-095
0.285" - - Swage Mount 0.125" 3/32 0.067 LEADED Red Brass Hot Solder Dip NO
09-7016-4-03
09-7016-4-03
09-7016-4-03
0.310" - - Swage Mount 0.150" 1/8 0.055 Brass Gold YES
09-0234-3-035
09-0234-3-035
09-0234-3-035
0.425" - - Swage Mount 0.115" 3/32 0.067 Brass Gold YES
09-8652-3-03
09-8652-3-03
09-8652-3-03
0.229" - - Swage Mount 0.125" 3/32 0.076 LEADED Red Brass Gold YES
09-8251-2-035
09-8251-2-035
09-8251-2-035
0.202" - - Swage Mount 0.098" 1/16 0.076 Brass Gold YES
09-8652-3-044
09-8652-3-044
09-8652-3-044
0.229" - - Swage Mount 0.125" 3/32 0.076 LEADED Red Brass Bright Tin YES
10-838-1-088
10-838-1-088
10-838-1-088
0.594" 0.050 Pin/Pin Swage Mount 0.063" 1/32 0.111 Brass Bright Tin-Lead NO
10-838-1-035
10-838-1-035
10-838-1-035
0.594" 0.050 Pin/Pin Swage Mount 0.063" 1/32 0.111 Brass Gold YES
10-831-1-035
10-831-1-035
10-831-1-035
0.251" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Gold YES
10-832-1-088
10-832-1-088
10-832-1-088
0.313" 0.050 - Swage Mount 0.063" 1/32 0.064 Brass Bright Tin-Lead NO
10-259-4-035
10-259-4-035
10-259-4-035
0.375" - - Swage Mount 0.156" 1/8 0.094 Brass Gold YES
09-0241-1-035
09-0241-1-035
09-0241-1-035
0.293" - - 2-56 - - 2-56 THREAD Brass Gold YES
10-259-2-035
10-259-2-035
10-259-2-035
0.312" - - Swage Mount 0.093" 1/16 0.094 Brass Gold YES
10-138-4-035
10-138-4-035
10-138-4-035
0.406" - - Swage Mount 0.156" 1/8 0.067 Brass Gold YES
10-710-3-044
10-710-3-044
10-710-3-044
0.562" - DOUBLE TURRET/THREAD Swage Mount 0.125" 3/32 0.144 Brass Bright Tin YES
10-615-3-095
10-615-3-095
10-615-3-095
0.475" - - Swage Mount 0.135" 3/32 0.090 Brass Hot Solder Dip NO
