Commercial
Non-Insulated
Terminals

Part No	Length	Pin Diameter	Feed Thru Combination	Mounting	Shank Length	Board Thickness	Hole Size	Terminal Material	Terminal Finish	RoHS
10-8008-3-035	0.525"	0.080	-	Swage Mount	0.125"	3/32	0.094	Brass	Gold	YES
10-931-3-035	0.281"	-	-	Swage Mount	0.125"	3/32	0.0635	Brass	Gold	YES
10-218-3-035	0.372"	-	-	Swage Mount	0.135"	3/32	0.094	Brass	Gold	YES
10-812-1-035	0.562"	-	Turret/Turret	Swage Mount	0.062"	1/32	0.147	Brass	Gold	YES
10-303-3-035	0.463"	-	-	Swage Mount	0.135"	3/32	0.116	Brass	Gold	YES
09-7010-2A-035	0.360"	0.050	-	Swage Mount	0.110"	1/16	0.055	Brass	Gold	YES
10-309-1-035	0.392"	-	-	Swage Mount	0.075"	1/32	0.116	Brass	Gold	YES
09-8044-1-035	0.371"	0.031	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8006-1-035	0.626"	0.020	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8485-2-035	0.402"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Gold	YES
10-421-3-035	0.604"	-	-	Swage Mount	0.135"	3/32	0.116	Brass	Gold	YES
10-137-3-035	0.300"	-	-	Swage Mount	0.141"	3/32	0.094	Brass	Gold	YES
09-8260-2-035	0.234"	-	-	Press Fit/Solder	0.078"	1/16	0.104	Brass	Gold	YES
10-901-4-035	0.312"	0.060	-	Swage Mount	0.156"	1/8	0.064	Brass	Gold	YES
09-8193-2A-035	0.377"	0.040	-	Swage Mount	0.097"	1/16	0.043	Brass	Gold	YES
09-0314-2-035	0.253"	-	-	Swage Mount	0.097"	1/16	0.047	Brass	Gold	YES
09-8193-2-035	0.392"	0.040	-	Swage Mount	0.082"	1/16	0.043	Brass	Gold	YES
10-990-1-035	0.571"	0.040	-	Swage Mount	0.051"	1/32	0.043	Brass	Gold	YES
09-8653-11-035	0.200"	-	-	Swage Mount	0.029"	1/64	0.037	Brass	Gold	YES
10-309-3-035	0.452"	-	-	Swage Mount	0.135"	3/32	0.116	Brass	Gold	YES
